BL A C K B O X
®
Extends a single-link DVI-D video signal
up to 130 feet (40.6 m).
Supports resolutions of 1280 x1024 (HDTV 1080i, 720),
1024 x 768, or 480p.
DVI Extender Kit
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax
724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,
PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com
Customer
Support
Information
May 2010
AC1035A-R2
Overview
Using CAT5e/6 cable, the DVI Extender
Kit extends a single-link DVI-D video
signal. It also:
• Provides a maximum resolution of
1280 x 1024 (HDTV 1080i, 720p) at
distances up to 100 feet (30.4 m) or
1024 x 768 (480p) at up to 130 ft.
(39.6 m).
• Requires no external power.
• Complies with RoHS, FCC, and CE
standards.
What’s Included
Your package should include the follow-
ing items. If anything is missing or dam-
aged, contact Black Box Technical Support
at 724-746-5500 or info@blackbox.com.
• DVI-D/RJ-45 transmitter
• RJ-45/DVI-D receiver
• This user’s manual
Installation
1. Power off the DVI-D output device
and DVI-D display.
2. Plug the transmitter into the DVI
output port of the DVI device. Use
CAT5e/6 cable that’s wired straight-
through. Plug the cable into the
transmitter and receiver. Connect the
receiver to the DVI display.
3. Power on the DVI display and the DVI
output device.
4. The green LED on the transmitter
indicates an active DVI-D video signal
and the orange LED indicates power
on.
Trademarks Used in this Manual
Black Box and the Double Diamond logo are
registered trademarks of BB Technologies, Inc.
Any other trademarks mentioned in this manual
are acknowledged to be the property of the
trademark owners.
©
Copyright 2010. All rights reserved.
