Clarion MAX675VDII DVD Player User Manual



59
MAX675VDII
English
Owner’s manual
5.1 ch Surround Decoder Operations
This function is available when an optional 5.1 ch
Surround Decoder (DVH940N) is connected.
When the 5.1 ch Surround Decoder is connected
through the CeNET cable, the 5.1 ch Surround
Decoder Control unit (DVC920, optional) cannot
be used.
5.1 ch Surround Decoder control
function
This section describes operation procedures of
setting functions.
For details on each function, refer to the owner’s
manual supplied with the 5.1 ch Surround
Decoder.
* Requires an optional amplifier.
Note:
The 2-ZONE mode is disabled when the DVH940N
is connected.
1. Press the [ADJ] button to display the ADJUST
menu.
2. Touch the [AUDIO EXT.] key.
3. Perform setting for the desired item.
See the following sections for details.
4. Touch the [Back] key to return to the previous
screen.
* In the following sections, only the details
regarding settings are described, procedures
to select setting items are skipped.
SPEAKER SEL (speaker selection)
This function determines center speaker,
surround speaker and subwoofer connection.
Dolby PLII CONTROL
* This function is available only when the MUSIC
MODE is selected for Dolby PLII. For setup
details, see “Selecting the Dolby PLII (Dolby Pro
Logic II) type” (page 62).
3-1. Touch the []] key of the SPEAKER SEL item
to show the submenu.
3-2. Touch the [ON] or [OFF] key of the CENTER
SP, SURROUND SP or SUBWOOFER item
to turn speakers on or off, depending on
what speakers are connected.
The factory default setting is “ON”.
The phase of the “SUBWOOFER” is
reversed in the “ON-” setting. The default
value is “ON+”.
3-1. Touch the []] key of the Dolby PLII
CONTROL item to show the submenu.
3-2. Perform setting for the PANORAMA,
DIMENSION or CENTER WIDTH item.
[PANORAMA]:
Touch the [ON] or [OFF] key to select. “OFF
is the default value.
[DIMENSION]:
Touch the [[] or []] key to adjust the level
between 0 and 6. The default level is “3”.
[CENTER WIDTH]:
Touch the [[] or []] key to adjust the level
between 0 and 7. The default level is “3”.
