DRL-100
DVD +R/ +RW Recordable Loader
ATAPI Interface
DVD+RW(4.7GB), DVD+R(4.7GB), DVD-RW(4.7GB Closed Session),
and DVD-R(4.7GB)
Readable DVD-5, DVD-9, DVD-10, DVD-18 Readable
Video-CD, CVD, SVCD, DVCD, CD-R, CD-RW and CD-Audio Readable
250ms Average Access Time in DVD & CD Mode
Supports 4.2X CAV Read Speed in DVD Mode
Supports 12X CAV Read Speed in VCD, CVD, SVCD
and DVCD Mode
Supports 12X CAV Read Speed in CD-Audio Mode
Supports 2.4x CLV Write Speed in DVD+R/DVD+RW
Maximum 5,775KB/sec Transfer Rate in DVD Read Mode
Maximum 1,800KB/sec Transfer Rate in VCD, CVD, SVCD and DVCD Read Mode
3,324KB/sec Transfer Rate in DVD+R, DVD+RW Write Mode
Power Tray Loading/Ejecting Mechanism
Built-in ATAPI Interface Controller
Built-in MODE-1 ECC/EDC
MTBF (T.B.D)
PIO Mode 4, UDMA 66 (T.B.D)
Sleep Mode for Energy Saving
Applicable Disc Format for Writing
DVD+R(ver 1.0), DVD+RW(ver 1.0, ver 1.1)
Error Rate
DVD Hard Error Rate : 10E-15 max.
Seek Error Rate : 10E-6 max.
CD Hard Error Rate : 10E-12 max. (Mode 1)
10E-9 max. (Mode 2)
Seek Error Rate : 10E-6 max.
Performance
FEATURESFEATURES
SPECIFICATIONS
MTBF (Mean Time Between Failures) : T.B.D
Tray Cycle Test
No fatal problem in the mechanical part after 10,000 times open/close cycle test.
Actuator Mechanism
The drive will be capable of seeking at least 1,000,000 full strokes.
MTTR (Mean Time to Repair) : 30 minutes
Quality and Reliability
DVS Korea Co.,Ltd.
5th, 7th & 8th Floor, KPS Bldg. 196 Kumgok-dong Boondang-ku, Sungnam City Kyungki-do 463-726, Korea.
Tel : 82-31-710-3800 / Fax 82-31-714-8312 http://www.dvs.co.kr / sales@dvs.co.kr
DVS America
1180 Aster Ave. Unit#F Sunnyvale, CA 94086 USA
Tel : 408-260-3301 / Fax : 408-260-3305 http://www.dvsystems.com / shaunk@dvsystems.com
This Loader should be used under the conditions listed below.
Environmental Conditions
Temperature and Humidity
Vibration
Operating
No unrecoverable error
10-500
Hz
sine sweep rate in 1 octave/min
Read0.25G, Write 0.1G
30 min/each direction
Non-Operating
No damage, No unrecoverable error
10-500
Hz
sine sweep rate in 1 octave/min
2G in X, Y and Z directions
30 min/axis
Shock
Operating (at a level surface)
No unrecoverable error
10 msec half-sine wave
Read 3G, Write 1G in 3 directions
1 pulse 10sec interval (6 each direction)
Non-Operating
No damage, No unrecoverable error
10 msec half-sine wave
50G 1 time in each direction
Drop (Packaged)
No damage, No unrecoverable error
Free drop at 70 cm
(1corner, 3edges, 6surface)
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Condensation
5 C to 45 C
-25 C to 60 C
10% to 80%
0% to 90%
No condensation of the conditions above
* Sustained Data Transfer Rate
DVD: Approx. Max 5,775KB/sec VCD : Approx. Max 1,800 KB/sec
* Burst (ATAPI)
16.7 Mbytes/sec (PIO Mode 4) T.B.D : 66 Mbytes/sec (UDMA 66)
Recordability
DVD+RW Jitter : Maximum 10% (Blank ALMEDIO disc, ADVP-WTP Manufactured
by Ricoh Measured on ref player DVD CATS SA300)
DVD+R Jitter: Maximum 11% (Blank ALMEDIO disc, ADVP-RTP4 Manufactured
by Ricoh Measured on ref player DVD CATS SA300)
DVD+RW Media (2.4x) : RICOH, Sony, Imation, Ridata, Melody
DVD+R Media (4x/2.4x) : RICOH, Sony, Imation, Verbatim(Mitsubishi),
That's(Taiyo Yuden), Mitsubishi, Melody
DVD+RW Rewrite : 1000times
DVD Read 4.2X(CAV) 2400 rpm CD Read : 12X(CAV) 2400 rpm
DVD+R/+RW Write : 2.4X(CLV)
Approx. 1,379 rpm to 3,333 rpm
Applicable Disc Format for Reading
DVD-5, DVD-9, DVD-10, DVD-18,DVD+RW(4.7GB), DVD+R(4.7GB),
DVD-RW(4.7GB Closed Session), DVD-R(4.7GB)
CVD, SVCD, DVCD, CD-R, CD-RW, VCD, CD-Audio
DVD Writable Media
Rotational Speed
Data Transfer Rate for Reading
Data Transfer Rate for Writing
Average Access Time
Data Buffer Capacity
DVD+R/+RW : Approx 3,324 KB/sec
Random Access DVD : 250 ms Typical CD : 250 ms Typical
: 2Mbytes
