WE ARE GOING GREEN!
A copy of your User Guide is not provided
in the box but is available online.
Go to www.dynexproducts.com, then click
Support & Service. Enter your model number
in the Search eld, then press Enter.
Click Support/Downloads.
Connecting a DVD or Blu-ray player, cable box,
satellite receiver, or game station
Using HDMI (best)
Using component cables (better)
Using composite cables (good)
Connecting an antenna/cable wall jack
Connecting a Home Theater System
Front features
Installing the stand
1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2 Align the stand to the TV and secure it to the stand column with the three
screws provided.
Installing a wall-mount bracket
1 Carefully place your TV screen face-down on a cushioned, clean surface to
protect the screen from damages and scratches.
2 Remove the screws that secure the
stand to the stand column, then
remove the stand.
3 Remove the screws that secure
the stand column to your TV, then
remove the column.
4 Attach the wall-mount bracket to
your TV using the mounting holes on
the back of your TV. See the instructions
that came with the wall-mount bracket for
information about how to correctly hang your TV.
Note: The COMPONENT IN jacks share
the audio jacks with the AV IN VIDEO
jack. Cables are often color-coded to
match color-coded jacks.
Note: The AV IN VIDEO jack shares the
audio jacks with the COMPONENT IN
jacks. Connect red to red, white to white,
and green to yellow.
This apparatus is intended to be supported by a UL Listed wall mount bracket.
Warning
TV stand
32" LCD TV
QUICK SETUP GUIDE
DX-32L200A12
Remote control and
two AAA batteries
Composite
cable
AC power cord
Three screws
Remote
control sensor
Power
indicator
Volume
+/-
Menu
Channel
▼/▲
Power
button
Input
Antenna or
cable TV
(no box)
Blu-ray player/DVD player/VCR
Cable or satellite TV box
AV receiver
Game console
or camera
Connecting a home theater system with multiple devices
We recommend that you connect
the AV receiver’s HDMI OUT jack
to your TV’s HDMI IN jack.
COMPONENT
OUT
AUDIO/VIDEO
OUT
O
U
T
IN
AN
T
E
NN
A
COAXIAL IN
M5 screws
Stand
M5 screws
Stand
Composite video
and analog audio
Connection type Video quality Cable connector
HDMI video/audio
Best
Component video
and analog audio
Better
Good
OR
OR
You can use an HDMI jack to connect a DVI device to your TV. You need to attach an
HDMI-to-DVI adapter to the end of the HDMI cable that connects to the DVI device’s jack.
Identifying cables
Your TV has several connection types for connecting devices. For the best video quality,
connect a device to the best available connection.
USB ash drive
