Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,
®
GE Profile
or
GE
®
appliance questions, visit our website at
ge.com or call GE Answer Center
®
service,
800.626.2000.
JBP70SK
GE
®
30" Free-Standing QuickClean
Electric Range
Listed by
Underwriters
Laboratories
R
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 5/05
321523
*Dimension from
wall to front of closed door handle
is 27-3/4"
.
KW Rating
240V
12
208V
9
Breaker Size
40 Amps
30
25
29-7/8
46-7/8
2-1/2
7-1/2
25-3/8*
47-5/8
2-1/2
Acceptab
le electr
ical
outlet area
30_install_fse_ge
.eps
*Dimension from wall to front of
closed oven door handle is 27-3/4
on models JBP84/81/80/72/70/66/
65/64/35/27/24 and JBS55.
