HP (Hewlett-Packard) LC3040N Flat Panel Television User Manual



6 Connect an S-video
Device
7 Connect a Composite
Device
5 Connect a Component
(YPbPr) Device
2 Connect Speaker Cables 3 Connect Subwoofer
(optional)
1 Attach Speaker Cables to TV
10 Remote Control
11 Turn On
8 Analog Video from PC
HP LC2640N (26") HD Ready LCD Television
HP LC3040N (30") HD Ready LCD Television
Start Here
Identify the type of connectors your home
entertainment equipment uses, then go to the
corresponding step on this poster and follow
those directions. (Example: To connect a cable
or satellite set-top-box which connects via
S-video cabling, refer to step 6, Connect an
S-video device.)
Refer to the user documentation for advanced
connections.
Apply power to all components and then to
the TV.
Finally, refer to the section titled “First Time
Setup for Channels” in your user
documentation to finalize your TV setup.
Contents
HP LCD TV with stand
Speakerbars (2)
Documentation kit
Remote control
with AA batteries (2)
Speaker cables (2)
Antenna cable
AC power cable
DVI cable
VGA cable
Component cable
S-video cable
Composite cable
The information in this document is subject to change without notice.
4 Connect a PC or Other
Device by DVI
9 Outdoor Antenna
Connection
Connectors are located on the back of the TV, under the back panel.
Remove rear door before making connections.
b
a
DVI
VGA
Once the power cable is connected, turn on TV by
pressing PWR on the remote control.
Refer to the section in the user documentation titled
“First Time Setup for Channels” to complete TV setup.
Refer to the user documentation for advanced connections.
OUT
R PbYPrL
Component Video Outputs
S-video Outputs
Composite Video Outputs
Wall
Coaxial
Cable
Signal
