Kenwood KMD-673R DVD Recorder User Manual



— 31 —
SOLUTIONPOSSIBLE CAUSEPROBLEM
A speaker cable may be pinched by a screw in the car. Check the speaker wiring.
No sound can be heard, or the
volume is low.
The fader and/or balance settings are set all the way to
one side.
Reset the fader and/or balance settings.
The input/output cables or wiring harness are connected
incorrectly.
Reconnect the input/output cables and/or the wiring
harness correctly. See the section on "Connecting
Cables to Terminals".
Nothing happens when the
buttons are pressed.
The computer chip in the unit is not functioning normally. Press the reset button on the unit (see page 4).
The sound quality is poor or
distorted.
The speakers are not wired correctly. Reconnect the speaker cables so that each output
terminal is connected to a different speaker.
The antenna control cable is not connected. Connect the cable correctly, referring to the section on
"Connecting Cables to Terminals".
Radio reception is poor. The car antenna is not extended. Pull out the antenna all the way.
The power does not turn on. The fuse has blown. After checking for short circuits in the cables, replace
the fuse with one having the same rating.
The Attenuator function is turned on. Turn off the Attenuator function.
No ACC position on vehicle ignition. Connect the same cable to the ignition as the battery cable.
The memory is erased when
the ignition is turned off.
The battery cable has not been connected to the proper
terminal.
Connect the cable correctly, referring to the section on
"Connecting Cables to Terminals".
The TEL mute function does
not work.
The TEL mute cable is not connected properly. Connect the cable correctly, referring to the section on
"Connecting Cables to Terminals".
The ignition and battery cable are incorrectly connected. Connect the cable correctly, referring to the section on
"Connecting Cables to Terminals".
The TEL mute function turns
on even though the TEL mute
cable is not connected.
The TEL mute cable is touching a metal part of the car. Pull the TEL mute cable away from the metal part of the
car.
What might appear to be a malfunction in your unit may just be the result of slight misoperation or miswiring.
Before calling service, first check the following table for possible problems.
Troubleshooting Guide
The value of “V OFFSET” is low. Increase the value of “V OFFSET”.
