Loewe 26 Projection Television User Manual



Xelos A 26
Purist. Modern design - graceful
contours.
Technical information
HD LCD technology with brilliant
picture in 16 : 9 format and 66 cm
screen diagonal.
Integrated DVB-T/DVB-C incl. CI.
Digital satellite reception may be
retrofitted.
HD ready. Optimum display of
high-definition HDTV content via
HDMI digital interface
Chrome Silver66416T87 4011880084888
Anthracite66416D87 4011880088145
Article number EAN Colour options
Designed by Vogel´s.[8]
Not available for special UK variants.[7]
A number of Loewe televisions are also available as fully interactive
Freeview compliant sets. (Art.no.s: Anthracite 66416D27, Chrome
Silver 66416T27)
[6]
Function depends on signal format emitted by station. [5]
Works only with channels broadcasting NexTView data. [4]
Setzt den Empfang eines Senders voraus, welcher NexTView-Daten
überträgt.
[3]
Dolby is a trademark of the Dolby Laboratories Licensing Corporatin.[2]
Panorama: can be converted to 14:9 format. [1]
Technical specifications, delivery conditions, and other
information are subject to change without notice.
Image:
Automatic Movie Detection (AMD)
Brightness cd/m²: 500
Contrast: 1,200 : 1
Digital+
Downscaling/upscaling
Format options: 16 : 9, 4 : 3, Panorama, Cine, Zoom [1]
HD LCD Technology
HD ready
Horizontal and vertical viewing angle: 176°
Image Basic
Image resolution: 1,366 x 768
PIP (AV)
Picture format: 16 : 9
Response time: 8 ms
Screen diagonal in cm: 66
Split Screen TV/Teletext
Vertical image correction
Audio:
Audio power amplifier output in watts: 2 x 20
Closed 2-way speakers
Number of speakers: 4
Panorama
Sound+
Two-channel stereo sound
Virtual Dolby Surround [2]
Radio:
Automatic station identification
Programme positions: 1,670
Radio function: with DVB-C/DVB-S
Operation:
Assist+
Automatic Channel Programming (ACP)
Automatic Signal Switch (ASS)
Automatic Volume Control (AVC) [5]
Automatic shut-off
Content-sensitive help
Current TV Programme
Digital Link
Digital Link Plus
Electronic Instruction Manual
Electronic Program Guide (EPG) [4]
Index
L-Link
NexTView-Link [3]
On Screen Display (OSD) in foreign languages:
D-E-I-F-NL-GB-P-PL-CZ-DK-S-HU-FIN-SLN-TR-SK-RS-GR
Parental Lock
Personalised teletext with direct access to bookmarked
pages
Power switch
Programme positions (incl. AV): 1,850
Remote control: RC 4
Standard values can be stored individually
Teletext: TOP-/FLOF Teletext/Level 2.5
Teletext page memory: 3,500 (2,000 with EPG)
Video Timer
via control unit: 4 keys
Reception:
Audio standard: BG/DK, Nicam, BG/L, I, DK
Colour standard: PAL, Secam, NTSC, NTSC 4.43 MHz
Hybrid tuner: DVB-T, DVB-C / analogue: cable, antenna [6]
Television standard: PAL: B/G, D/K, I, L, M/M; PAL 60;
Secam: B/G, D/K, L, NTSC M
Connectors:
AV: on side of device
Antenna (analogue/digital)
Audio In (Cinch)
Audio Out, controlled (Cinch)
Common Interface
Component (YUV) input
Copy function Euro-AV <-> Euro-AV
Copy function Front-AV --> Euro-AV
Digital-Audio In (Cinch)
Digital-Audio Out (Cinch)
Euro-AV/Scart total: 2
Euro-AV/Scart, of which the following number are
Component Video Input-ready: 1
Euro-AV/Scart, of which the following number are
RGB-ready: 1
Euro-AV/Scart, of which the following number are
S-VHS/Hi8-ready: 1
HDMI including HDCP
Headphones: 3.5 mm (on side of device)
Hosiden input: on side of device
VGA
Video In (cinch)
Optional function upgrades:
DVB-S (Single-Tuner) [7]
Accessories:
Set-up solutions: Floor Stand 4
Standard feature: TS 55 tabletop stand
Wall Mount: WM 52, VESA-Adapter LCD, Screen Wall
Mount 1 [8]
Miscellaneous:
Annual power in kWh: 120
Mains voltage: 220-240 V, 50/60 Hz
Power consumption in standby mode in watts: 2.7
Power consumption in watts when the set is turned off: 0
Rated wattage to EN 62087: 70
Tilt function
VDE-safety standard (inspection seal)
Weight (net) in kg: 14,0
