Login and connect equipment
You have logged in and connected all connected equipment in the initial
start-up. If you want to connect other equipment or disconnect equipment,
call the connection wizard.
Call up the TV menu
Mark “Connections”
Mark the submenu line
Mark “New equipment/changes“ and ...
call with OK.
State what equipment you want to connect. The connection wizard then
shows you which sockets you should connect this equipment to. Then con-
nect the equipment to these sockets.
Connecting video/DVD recorders
In addition to the connection via the Euro-AV sockets you also have to con-
nect the antenna (only for terrrestrial antenna or cable systems) through the
VCR/DVD recorder to the TV set. The antenna signal is then available to the
video/DVD recorder and the TV set.
Note: Use Euro AV cables with righ-angled plugs as shown.
Search for and store the station of the video recorder (if no Euro AV cable is
available).
ENTREE
ANTENNE
EURO AV2
DECODER
EURO AV1
AUDIO/
VIDEO
SORTIE
ANTENNE
AERIAL
RF OUT
SORTIE
GL
D
R
OUT
AUDIO
Search for and store the station of the video recorder (if no Euro AV
cable is available)
Switch on the test station on the VCR or insert a recorded tape and start
playback. In some video recorders the station must be switched on by
activating the modulator.
Then call the AV selection on the TV set with 0 AV. Select the menu item
“VIDEO“ in the AV selection and call with OK.
To prevent “normal” TV stations being found in the search, pull out the
antenna plug from the antenna input of the VCR temporarily (the cable to
the antenna system).
If you cannot see the test station or playback from the cassette, the VCR is
transmitting on a different channel. You then have to search for the station
or set it manually.
Call the TV menu with the MENU button.
Select the „Settings“ menu item with 34.
Select the line below it with 6and “Channels“ with 34.
Select the line below with 6and “Manual adjustment“ with 34and
call this menu with OK.
Enter channel “E30“ under the “Channel“ item (UHF range, select in this
menu above if necessary).
Start search with the blue button.
If the station has been found, enter the name VIDEO, confi rm with OK
and save with the red button.
A list of the stored stations is displayed
Select 0 (VIDEO) here and overwrite this program place with the red
button.
Hide the menu again with the MENU button.
Plug the antenna plug back in.
If you now get interference because a TV station is transmitting on the
same channel as the VCR station, you have to change the transmitting sta-
tion on the VCR and search for the VCR station on the TV again.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Operating additional equipment
OK
OK
OK
OK
MENU
