Pre-Configured Solution
NEC 2x2 LCD TileMatrix™ Video Wall Solutions
40"/46”/52” LCD Display/Mounting System/Cabling/Power Suppression
NEC Display Solutions’ complete 2x2 LCD TileMatrix Video Wall Solutions
provide for an all-in-one, easy-to-configure solution that is ideal for dynamic
digital signage, information display and command & control applications.
Exclusive TileMatrix and TileComp™ technologies, combined with the ultra-
thin bezel design of NEC MultiSync 20 Series displays, provide for a near
seamless video wall without the need for additional third-party equipment.
When compared to 82”-108” single-screen displays, NEC’s video wall solu-
tions deliver a more cost-effective and easier-to-transport and install alterna-
tive for your application.
LCD technology alleviates downfalls affiliated with rear-projection and plas-
ma displays. This includes improved color and brightness uniformity as well
as full HD resolution (LCD5220-TMX4) for stunning video clarity. In addition,
one need not worry about the added expense of costly replacement lamps.
Solution Features and Benefits
TileMatrix allows you to build video walls up to 25 displays using only
one video source. This helps avoid the hassle and extra costs of using
splitters or connecting monitors to multiple sources.
TileComp works in tandem with TileMatrix to compensate for the
bezel width and create a more seamless video wall
The ultra-thin-bezel design of the MultiSync 20 Series (as thin as
0.61 in. / 15.5mm) is one of the smallest in the industry
XtraView® wide-angle viewing technology delivers flexible horizontal
and vertical viewing angles with less glare, reflection and distortion
Rapid Response™ technology delivers virtually uninterrupted, undis-
torted viewing of high-speed, full-motion video
6-axis color control engine allows for precise and simplified color,
color temperature (2600 - 10,000K) and saturation adjustment
The high-efficiency backlight reduces not only the power consumption
but also the heat generation at the front of the screen. In addition,
internal temperature sensors work in tandem with thermostatic cooling
fans to continuously monitor the interior temperature of the display,
control self-protective circuits and minimize heat damage.
Real-time clock allows for content scheduling and monitor sleep/wake
management, improving energy savings and extending display life
NaViSet™ software utilizes the monitor’s advanced control and diag-
nostics capabilities to provide AV and IT professionals with remote
access to monitor settings over their existing network. This can be
used in combination with daisy chain-enabled RS-232C to control
individually addressable displays.
Digital Factory PerfectAlign mounting system is compact and slim,
which allows the displays to be mounted as close to the wall as possible
Extron® cables are premium quality and provide uncompromising high
resolution signal distribution and multipurpose interconnectivity solu-
tions for a wide range of professional, commercial, residential, themed
entertainment and live event AV environments
Tripp Lite surge suppressor, featuring six outlets and $50,000 ultimate
lifetime insurance, prevents system crashes, reboots and performance
problems
Public Information &
Digital Signage
Retail advertising/branding
Hospitality
Corporte lobbies
FIDS/GIDS/BIDS
Tradeshows
Houses of worship
Higher education
Command & Control
Utilities
Defense
Homeland Security
Weather stations
Call centers
Traffic management
Broadcast stations
NOCs
TARGET
MARKETS
