[] Control Panel
[] Rear Panel
rear of this unit
side of this unit
rear of this unit
1. POWER button (p13)
Press to turn the unit on and off,
2, INPUT SELECT button (p17)
• Press to access connected an external device _ike a
1
DVD player or VCR,
2 Press to decide the command of setting when the
menu is displayed.
3
3. CHANNEL--IV buttons (p16)
Press to select channels or move up/clown through the .....
'4 main menu items.
'5 4. VOLUME_/buttons (p16)
Press to adjust the volume or move right ( _)/left (_) ,,:
through the main menu items.
5. SETUP button (p14) :i:
6 Press to display the main menu ....
6. Infrared Sensor Window
Receives infrared rays transmitted from the remote
control.
.3
:54
-6
_:i¸
side of this unit
1. PC-IN jack (p12)
VGA cable connection for PC,
2. HDMIINjacks (pg) i;
HDMI connection foran HDMI device, _=
3. AUDIO IN jacks (p9) ::
RCA audio cable connection for a DVl device. (For
HDMI l-IN jack only) .....
4. AUDIO OUT jacks (p11)
RCA audio cable connection for an external device.
Use analog audio input jacks of an external device,
5. DIGITAL AUDIO OUT (COAXIAL) jack (pl 1)
Digital audio coaxial cable connection for a decoder or
an audio _eceiver.
Use digital audio input jack of an external device .....
6, ANT, IN jack (p8)
RF coaxial cable connection for your antenna or
cable/satellite box.
7. AC power cord
Connect to a standard AC outlet to supply power to
this unit.
8. PC-IN AUDIO jack(p12)
Mini-plug audio cable connection for PC.
Use line out jack of a PC,
9. AUDIO input jacks (plO)
RCA audio cable connection for an external device.
10. VIDEO input jack (pl 1)
RCA video cable connection for an external device.
1I. S-VIDEO input jack (plO)
S-video cane connection for an external device.
12. COMPONENT and AUDIO input jacks (pl O)
Component video cable and RCA audio cable
connection for an external device.
Use component video and audio output jacks of an
external device.
