Sylvania SSR90V4 DVD Recorder User Manual



Connections
14
DVD/VCR
ANTENNA
IN
OUT
RF Cable
(supplied)
(Back of this unit)
IN
OUT
E
(Back of TV)
Cable
Signal
Connection A
(Cable box or
Satellite box)
Connection to a cable box or satellite box
Note to the Cable TV System Installer :
This reminder is provided to call the Cable TV system installer’s attention to Article 820-40 of the
National Electrical Code, which provides guidelines for proper grounding - in particular, specifying that the
cable ground shall be connected to the grounding system of the building, as close to the point of cable
entry as possible.
Select this connection when you want to view or record a scrambled channel.With this connection, channels
cannot be changed on this unit.You can view or record ONLY the channels you have selected on the cable
box or the satellite box.
• While you are recording, only the recorded channel can be viewed.
To select channels of the cable box or satellite box
1) Turn on this unit by pressing POWER button. The power indicator on the front panel will appear. Then,
press the CHANNEL buttons to select channel 3 or 4 (the same channel as the output channel of the
cable box or satellite box).
• If noise appears on the TV screen
,press VIDEO/TV button on the remote control.
• If you use the channel 4, you will need to change this unit’s RF output to channel 4. Refer to “RF converter
output” on page 100.
2) At the TV, select channel 3 or 4 (the same channel as you have selected at step 1).
3) At the cable box or satellite box, select the channel you want to view or record.
DVD/VCR
ANTENNA
IN
OUT
RF Cable (supplied)
RF Cable
(Back of TV)
IN
OUT
(Cable box or
Satellite box)
E
Cable
Signal
Connection B
(Back of this unit)
Select this connection when you want to change channels on this unit.With this connection, you may watch
one channel while recording another.
• You may not view or record a scrambled channel.
To select channels of the cable box or satellite box
1) At the cable box or satellite box, select channel 3 or 4 (the same channel as this unit’s RF output chan-
nel.)
• Refer to “RF converter output” on page 100.
2) At the TV, select the same channel as the output channel (3 or 4) of the cable box or satellite box.
3) Turn on this unit by pressing POWER button. The power indicator on the front panel will appear. Then
select the channel you want to view or record.
• If noise appears on the TV screen
,press VIDEO/TV button on the remote control.
To playback a DVD disc or a tape
Before trying to playback DVD or tape, you MUST follow steps 1) to 2) above.
• Refer to “Playback” on pages 44-45, 94.
To view one channel while recording another
1) While you are recording on this unit, press VIDEO/TV button.
2) At the cable box or satellite box, select the channel you want to view.
