77
RQT9434
Convenient
functions
Easy control only with VIERA remote
control
If you connect this unit to the TV that has “HDAVI Control 2” or later
function with an HDMI cable, you can enjoy using more convenient
functions.
You can operate this unit using buttons on the TV remote control.
The buttons that you can use for this unit vary depending on the TV.
For details, refer to the operating instructions of the TV.
Use the remote control supplied with this unit if you cannot operate
this unit using buttons on the TV remote control.
≥The operation of this unit may be interrupted when you press
incompatible buttons on the TV remote control.
Using the FUNCTION MENU window to operate
this unit
[VIERA]Link]
§1
Refer to the TV operating instructions for operating the TV.
1 Display this unit’s “FUNCTION MENU” window
using the TV remote control.
≥If this unit is set to standby mode, it will automatically turn on.
2 Select the item you want to operate with the TV
remote control, and press [OK].
≥About the FUNCTION MENU window (> 13).
Pause Live TV programme [VIERA]Link]
§2
You can pause the TV programme you are watching and resume
later by temporarily saving it on the HDD. This is useful when you
have to briefly stop watching TV to run an errand.
If you stop the Pause Live TV function, then the TV programme
temporarily saved on the HDD will be deleted.
Refer to the TV operating instructions for operating the TV.
1 When you want to pause the TV programme
Turn on the “Pause Live TV” function using the
TV remote control.
≥This unit turns on automatically.
2 When you want to resume
Display the Control Panel (> right) and press
[OK].
≥The TV programme resumes.
To stop Pause Live TV
1 Press [4] while the Control Panel is displayed.
2 Press [2, 1] to select “Yes” and press [OK].
[Note]
≥Subtitles are not displayed correctly if the setting for Subtitle
Character Set is different between this unit and the TV.
≥This function does not work with TV’s analogue broadcast
programmes during EXT LINK standby or recording.
Refer to other “Note” on page 79, “To pause the TV programme you
are watching—Pause Live TV”.
Using the OPTION menu window to operate this
unit
[VIERA]Link]
§1
By using the TV remote control, you can play discs using the
“Control Panel” (> below) and display the Top Menu for DVD-
Video.
1Press [OPTION].
[Note]
OPTION menu may be disabled when
operating the BD-Video or DVD-Video.
2 Select an item then press [OK].
Control Panel Control Panel is displayed
(> below).
Switch to TV Displayed when watching digital
satellite broadcasts with the tuner of
this unit. It will return to the TV
picture.
FUNCTION MENU FUNCTION MENU window is
displayed (> left).
Aspect
Switch the screen mode
(
>
83
).
Multi Audio
Switch the signal
(
>
28
).
Sub Channel
Subtitle Language
Play Menu
Play Menu is displayed
(
>
82
).
Top Menu [BD-V] [DVD-V] Top Menu is displayed (> 21).
Menu [DVD-V] Menu is displayed.
Pop-up Menu [BD-V] Pop-up Menu is displayed.
Drive Select Select the HDD, BD or SD drive
Rotate RIGHT (JPEG) Rotate the still picture (> 65).
Rotate LEFT (JPEG)
Zoom in (JPEG) Enlarge or shrink the still picture
(> 65).
Zoom out (JPEG)
TV Power Off Play music continuously even after
turning off power to the television
(> 72).
∫ Using the Control Panel
Using the Control Panel, you can operate search backward, search
forward, stop, etc, with the TV remote control.
Perform steps 1 and 2 of “Using the OPTION menu window to
operate this unit [VIERA]Link]
§1
” (> above).
The Control Panel is displayed (> below).
≥When playing a title or DVD-Video, etc.
–[3]: Pause, [4]: Stop, [2]: Search backward, [1]: Search
forward, [OK]: Play, [EXIT]: Exit the Control Panel.
≥While playing still pictures
–[4]: Stop, [2]: View previous picture, [1]: View next picture,
[EXIT]: Exit the Control Panel.
§1
This function is available with the TV that supports “HDAVI
Control 2” or later.
§2
This function is available with the TV that supports “HDAVI
Control 3” or later.
∫ When you want to leave the TV on and set only
this unit to standby mode
Press [Í] on this unit’s remote control and set to standby mode.
∫ When not using “HDAVI Control”
Set “VIERA Link” in the Setup menu to “Off” (> 93).
e,g.,
Top Menu
Play Menu
Menu
Control Panel
Drive Select
Aspect
FUNCTION MENU
OK
RETURN
Control Panel
Exit
