C421M-D (4/00)
HT10 Series
Liquid-Cooled Enclosure
®
IMPORTANT SAFEGUARDS AND WARNINGS
Prior to installation and use of this product, the following WARNINGS should be observed.
1. Installation and servicing should only be done by qualified service personnel and conform
to all local codes.
2. Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X ,6 or 6P
enclosure, it is designed for indoor use only and it must not be installed where exposed to
rain and moisture.
3. Only use replacement parts recommended by Pelco.
4. After replacement/repair of this unit’s electrical components, conduct a resistance
measurement between line and exposed parts to verify the exposed parts have not been
connected to line circuitry.
5. The installation method and materials should be capable of supporting four times the
weight of the enclosure, pan/tilt, camera and lens combination.
6. Use or mount this enclosure so that it is positioned not less than 91 degrees and not
more than 180 degrees when considering 12 o’clock to be 0 degrees and 6 o’clock to be
180 degrees.
7. Only Nema 3R liquid tight conduit should be used in all outdoor applications.
The product and/or manual may bear the following marks:
This symbol indicates that danger-
ous voltage constituting a risk of
electric shock is present within
this unit.
This symbol indicates that there
are important operating and main-
tenance instructions in the litera-
ture accompanying this unit.
Please thoroughly familiarize yourself with the information in this manual prior to installation
and operation.
DESCRIPTION
The products in the HT10 Series are liquid-cooled enclosures designed for high temperature
applications.
The stainless steel enclosure features two separate double-walled cooling jackets that protect
the camera and lens and other sensing devices housed within the unit.
Models
HT10V High temperature enclosure with Vycor
®
window; window suitable in
temperatures up to 1300°F (705°C)
HT10V/RC Same as the HT10V except Vycor window has an infrared reflective coating
for environments where high levels of radiant heat are encountered; window
suitable in temperatures up to 1300°F (705°C)
CAUTION:
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
