XBR-65X810C / 55X810C
4-576-185-11(1)
US
MHL (HDMI IN 2)
Video:
4096 × 2160p (24 Hz)*, 3840 × 2160p (24,
30 Hz), 1080p (30, 60 Hz), 1080/24p, 1080i
(60 Hz), 720p (30, 60 Hz), 720/24p, 480p,
480i
* 3840 × 2160p is displayed when 4096 ×
2160p is input
Audio: 5.1 channel linear PCM: 32, 44.1, 48,
88.2, 96, 176.4 and 192 kHz, 16, 20 and
24 bits, Dolby Digital and DTS
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM,
Dolby Digital, DTS)
AUDIO OUT / (Stereo mini jack)
Headphone, Audio output, Subwoofer
1, 2, 3
USB port 1 and 2 support High Speed USB
(USB2.0).
USB port 3 supports Super Speed USB
(USB3.0).
LAN
10BASE-T/100BASE-TX connector
(Connection speed may differ depending on
the network environment. 10BASE-T/
100BASE-TX communication rate and
communication quality are not guaranteed
for this TV.)
Home Network
Refer to the Help Guide for supported
formats.
REMOTE
RS232C, Serial Control mini jack; IR IN mini
jack.
These jacks are for receiving the external
control signal.
Others
Optional accessories
Touchpad Remote Control: RMF-TX100U
Wireless Subwoofer: SWF-BR100
MHL Cable: DLC-MC20
4K Media Player: FMP-X10 (U.S.A. only)
Operating temperature
32 ºF – 104 ºF (0 ºC – 40 ºC)
Power and others
Power requirement
110 V - 240 V AC, 50/60 Hz (U.S.A./Canada
120 V AC, 60 Hz)
Power consumption
in use
XBR-65X810C: 225 W
XBR-55X810C: 196 W
in standby*
Less than 0.5 W with 120 V AC and less than
0.5 W with 240 V AC
Screen size (inches measured diagonally)
(Approx.)
XBR-65X810C: 64.5 inches (65 class)
XBR-55X810C: 54.6 inches (55 class)
Display resolution
3,840 dots (horizontal) × 2,160 lines (vertical)
Output Rating
USB 1
5 V, , 500 mA MAX
USB 2
5 V, , 500 mA MAX
USB 3
5 V, , 900 mA MAX
MHL (HDMI IN 2)
5V, 1.5 A MAX
* Standby power consumption will Increase
when network connected.
Dimensions (Approx.)
with stand
XBR-65X810C: 1,463 × 901 × 306 mm / 57
5
/
8
× 35
1
/
2
× 12
1
/
8
inches
XBR-55X810C: 1,245 × 770 × 246 mm / 49
1
/
8
× 30
3
/
8
× 9
3
/
4
inches
without stand
XBR-65X810C: 1,463 × 852 × 81 mm / 57
5
/
8
×
33
5
/
8
× 3
1
/
4
inches
XBR-55X810C: 1,245 × 730 × 80 mm / 49
1
/
8
×
28
3
/
4
× 3
1
/
4
inches
wall-mount hole pattern
300 × 300 mm
wall-mount screw size (mm)
M6 (length: see diagram on page 17.)
Mass (Approx.)
with stand
XBR-65X810C: 23.3 kg / 51.4 lb.
XBR-55X810C: 18.4 kg / 40.6 lb.
without stand
XBR-65X810C: 21.8 kg / 48.1 lb.
XBR-55X810C: 17.3 kg / 38.2 lb.
Note
• Optional accessories availability depends on
countries/region/TV model/stock.
• Design and specifications are subject to change
without notice.
• This TV set incorporates MHL 3.
