Operating Manual
for 2 in 1 Cable TV
Remote Control
UR-S86TVE
Universal Remote Control, Inc.
www.universalremote.com
OCE-0003E Rev 02(05/14/02)
This remote control is preprogrammed to operate
CABLE Box. Please program it for your TV by
following the instructions shown below.
Instructions
Batteries
Programming your remote control
Install two AAA alkaline
batteries as shown here
The remote control uses AAA batteries. Please be sure
to match the batteries with the (
+
) and (- ) markings
inside the battery compartment during installation.
STEP2
Press [TV] and [MUTE] buttons simultaneously
until the red light is on.
STEP3 Point the remote control toward the TV and
enter the three-digit code from the code table. If there
is more than one code number assigned to your TV
brand, try one code number at a time until the TV
turns off right after you entered the number.
Searching Method
Press [CH +] button and hold until the TV turns off. As
soon as the TV turns off, release [CH+] button.
*Tip : You can confirm the power off and on by
pressing [MUTE] button.
STEP4 Press [TV] button to store the three-digit
code.
*Tip :
Red light
will blink twice.
Three-digit code :
STEP2 Press [CH +] button.
*Tip : Red light will blink twice.
The [POWER] button sends out the TV and CABLE
power commands if you press the [POWER] button.
To return to the original function, press the [CH-]
button in the STEP2 .
B. Recalling the TV Three-digit code :
STEP1 Press [ TV ] and [ MUTE ] buttons
simultaneously until the red light is on.
STEP2 Press [VOLUME -] button.
The red light will blink a number of times indicating the
number of each digit of the code. Each digit is
separated by one second interval of red light being off.
*Tip : One blink, three blinks and 10 blinks,
indicates the code number 130.
The remote control is preprogrammed to control
VOLUME and MUTE functions through your TV. To
switch VOLUME and MUTE functions to your Cable Box:
STEP1 Press [POWER] and [MUTE] buttons
simultaneously until red light is on.
STEP2 Press [VOLUME +] button.
STEP3 Press [POWER] button.
To return to the TV’s VOLUME, press [TV] button.
*Tip : Red light will blink twice.
Set-up for advanced functions
A. To turn on your TV and Cable at the same time
with
POWER button:
STEP1 Press [ POWER ] and [ 0 ] buttons simultaneously
until the red light is on.
Set-up for your VOLUME control
Set-up for your Cable Box
The remote control is preprogrammed to control
your cable box. If it does not work properly, please
set-up the right code by using the three-digit code
or searching method.
If you have a TV with a remote control, we
recommend that you plug its power cord directly
into a wall outlet if available (your cable installer
may select an alternate setup)
Operation
If red light does not blink when you press keys the
operation is intermittent:
Make sure the batteries are inserted correctly.
Replace old batteries with two new AAA batteries.
Please do not mix old batteries with new ones.
Helpful hints
Press arrow gently &
pull down to remove cover
Setup for your cable box
No setup is required. The remote control is
preprogrammed to operate your cable box.
Setup for your TV
Find your TV brand and its three-digit code on the
back of this manual. If the TV brand is not listed,
please use the Searching Method in STEP3 .
STEP1 Turn on your TV manually.
*Tip : If you have RCA TV, don’t turn on the TV.
