-4-
598-1073-02
12345678
Inside
Transmitter
Transmitter Battery Replacement
Install an alkaline type A23 12 Volt bat-
tery. See diagram inside push button for
correct battery orientation.
* Code Settings 1-7
Must Match Both
Transmitter and
Chime
Remove screw to
open access door
Back of
Chime
Tune Setting
Tune Setting
(Not used on
all models)
Note: Some models might re-
quire the use of tweezers to re-
move and replace the jumpers.
Tune Settings
Your wireless chime has different selectable tunes: Ding (one note), Ding-
Dong (two note), or Westminster (eight note) (Available on selected chimes).
The factory setting is for the Ding-Dong tune (or Westminster, when avail-
able). This tune can be changed by following the instructions below.
• Ding (one note tune)
Transmitter: Add a jumper to location 8.
• Ding-Dong (two note tune)
Transmitter: Remove jumper from location 8.
Chime: Remove jumper from location 8.
• Westminster (Eight note tune) (Available on selected chimes)
Transmitter: Remove jumper from location 8.
Chime: Add a jumper to location 8.
Note: All models have both front and back door tune capabilities. You may
purchase any ACE
®
wireless push button for a second entrance.
12345678
