PREPARATION
IMPORTANT: Do not apply pressure to the
screen display area which may compromise
the integrity of the display. The manufacturer’s
warranty does not cover user abuse or
improper installations.
ATTACHING THE BASE
IMPORTANT: The Base of the HDTV must
be assembled prior to usage.
1. Place TV unit face down on a soft and
flat surface (blanket, foam, cloth, etc.) to
prevent any damage to the TV.
2. Carefully align and insert the Base to
the stand.
3.
For 26"/32"/42" model: Insert 3 screws
for 26” model or 4 screws for 32"/42"
model to the bottom of the base and
tighten the base to the stand.
For 26"/32" model
For 42" model
PREPARING YOUR LCD HDTV FOR
WALL MOUNTING
We suggest that you keep your TV at least 2.36
inches (60 mm) from the wall to prevent cable
interference.
Before mounting your TV on the wall, you need
to remove the base.
For your safety, please use listed wall mount
bracket with minimum weight of the TV
without stand. (Please see page.2 .)
To attach a wall mount bracket to your TV:
1 Loosen the screws holding your TV to
the stand and remove the stand base
from the TV.
2 Secure the wall mount bracket to the
back of your TV using four screws, as
indicated in the illustration.
For 26" model
200 mm
100 mm
M4 screws
6
For 32" model
200 mm
200 mm
