PREPARATION
Remove the back plate at the back of the TV as shown on the illustration
opposite. Lay the LCD TV with the screen down on a table, as it will be easier
to connect your peripheral equipment. Please take precaution not to damage
the screen.
①
1: RF TV port
②
2: Earphone output port
③
3: Right audio input port
④
4: Left audio input port
⑤
5: AV video port
⑥
6: S-VIDEO video port
⑦
7: power input port
16
