CD/DVD OPERATION
This owner’s manual explains the basic instructions of this unit. Some DVDs are produced
to limit operation during playback. For example, many DVDs do not allow users to skip
government warnings, or in some cases previews or other features. This is not a defect in
the unit. Refer to the instruction notes of discs.
“
” may appear on the screen during operation. A “ ” means that the desired
operation is not permitted by the unit or disc.
PLAYING A DISC
1. Press the STANDBY/ON button (on unit or remote control) to turn on the unit.
2. Press the FUNCTION button to select DVD mode.
See CUSTOMIZING THE DVD FUNCTION SETTINGS before proceeding to step 3.
3. Press the
OPEN / CLOSE button to open the disc door.
4. Hold the disc by its sides and carefully press onto the central support of compartment with
the printed side facing towards you until you hear a “click”.
5. Press the
OPEN / CLOSE button to close the disc door.
It takes a short while for your unit to load the disc. After loading, the unit will automatically
either bring you to the main menu of the DVD, or start playing the DVD. If the unit does not
automatically start playing the DVD, press the
PLAY button.
PAUSING PLAYBACK (STILL MODE)
Press the PAUSE button. To resume normal playback, press the PLAY button. Each time you
press the
PAUSE button, the picture advances one frame.
SLOW-MOTION PLAY (DVD)
1. Press the SLOW button on remote control in the play mode. Two speeds are available.
Each time the
SLOW button is pressed, the speed of slow-motion playback changes in the
following sequence:
SF 1/2
SF 1/3 SF 1/4 SF 1/5 SF 1/6 SF 1/7
2. Press the PLAY button to return to the normal playback speed.
SKIP (FORWARD / REVERSE)
• Press the PREV button to go back to previous chapters/tracks.
• Press the
NEXT button to advance chapters/tracks.
• For an Audio CD, use the number buttons (remote control only) to jump directly to that track
number.
STOPPING PLAYBACK
Press the STOP button at the location where you want to interrupt playback. To resume
playback at the position where the disc was stopped, press the
PLAY button.
If you press the
STOP button twice, the unit’s memory will be cleared and pressing the
PLAY button will reset the disc to the beginning.
FAST FORWARD/FAST REVERSE
1. Press the SEARCH or SEARCH button when a disc is playing.
• The disc begins fast scan at x2 speed.
• Four speeds are available. Each time the SEARCH
or SEARCH button is pressed,
the speed of fast scan changes in the following sequence:
X 2
X 4 X 8 X 20
2. Press the PLAY button when you reach the desired point to resume playback at normal
speed.
