Indoor Indoor Indoor / Outdoor Indoor / Outdoor Indoor / Outdoor Indoor / Outdoor Indoor / Outdoor Indoor / Outdoor
AXIS 212 PTZ
2
AXIS 212 PTZ-V
2
AXIS 213 PTZ
1
AXIS 214 PTZ
1
AXIS 215 PTZ
1
AXIS 231D+
1
AXIS 232D+
1
AXIS 233D
Image sensor
1/2” progressive
scan CMOS
3 megapixel
1/2” progressive
scan CMOS
3 megapixel
1/4” CCD
1/4” ExView
HAD CCD
1/4” CCD
1/4” ExView
HAD CCD
1/4” ExView
HAD CCD
1/4” ExView
progressive scan
HAD CCD
Lens
2.7 mm/F1. 8
fixed iris
3x instant zoom
2.7 mm/F1. 8
fixed iris
3x instant zoom
3.5 - 91 mm
auto iris and auto focus
26x optical zoom
12x digital zoom
4.1 - 73.8 mm
auto iris and auto focus
18x optical zoom
12x digital zoom
3.8 - 46 mm
auto iris and auto focus
12x optical zoom
4x digital zoom
4.1 - 73.8 mm
auto iris and auto focus
18x optical zoom
12x digital zoom
4.1 - 73.8 mm
auto iris and auto focus
18x optical zoom
12x digital zoom
3.4 - 119 mm
auto iris and auto focus
35x optical zoom
12x digital zoom
Day and night
Configurable
Built-in IR lamp
Automatic Automatic Automatic Automatic
Min illumination/
light sensitivity (lux)
10 lux wide mode
20 lux tele mode
10 lux wide mode
20 lux tele mode
1 (color)
0.1 (B/W)
0.3 (color)
0.005 (B/W)
1 (color)
0.3 (B/W)
0.3 (color)
0.3 (color)
0.005 (B/W)
0.5 (color)
0.008 (B/W)
Video compression
MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG MPEG-4, Motion JPEG
Max video resolution (pixels)
640 x 480 640 x 480 4CIF: 704x480 4CIF: 704x480 4CIF: 704x480 4CIF: 704x480 4CIF: 704x480 4CIF: 704x480
Frames per second
30 (640x480) in overview 30 (640x480) in overview 30 (4CIF) 30 (4CIF) 30 (4CIF) 30 (4CIF) 30 (4CIF) 30 (4CIF)
Pan/Tilt/Zoom
20 presets
140° pan
105° tilt
Guard tour
20 presets
140° pan
105° tilt
Guard tour
20 presets
340° pan
100° tilt
20 presets
340° pan
120° tilt
20 presets
360° pan via auto-flip
180° tilt
50 presets
360° endless pan
90° tilt
Guard tour
50 presets
360° endless pan
90° tilt
Guard tour
100 presets
360° endless pan
180° tilt
Guard tour
Audio support
Two-way Two-way Two-way with AXIS 213CM Two-way Two-way Two-way
Alarm in-/outputs
1/1 1/1
2/3 with AXIS 213CM
3
1/1 1/1 4/4 4/4 4/4
Intelligent video
Motion detection
Audio detection
Motion detection
Audio detection
Motion detection
Motion detection
Audio detection
Motion detection
Audio detection
Motion detection Motion detection
Motion detection
Audio detection
Security
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Multi-level passwords
IP filtering
Multi-level passwords
IP filtering
HTTPS encryption
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Multi-level passwords
IP filtering
HTTPS encryption
IEEE 802.1X
Network
IPv4/v6, QoS IPv4/v6, QoS IPv4 IPv4/v6, QoS IPv4/v6, QoS IPv4/v6, QoS IPv4/v6, QoS IPv4/v6, QoS
Power over Ethernet
(IEEE 802.3af)
Class 1 Class 1
PoE active splitter available
#0170-004-01
Serial connectors RS-232 with AXIS 213CM
3
Outdoor use
Outdoor use requires
weather-proof housing
Outdoor use requires
weather-proof housing
Outdoor use requires
weather-proof housing
Outdoor use requires
weather-proof housing
Outdoor use requires
weather-proof housing
Outdoor use requires
weather-proof housing
Other
Continuous motion 24/7
Continuous motion 24/7
Vandal-resistant
Built-in IR light up to 3 m
Analog video with
AXIS 213CM
3
Auto-flip and E-flip
Continuous motion 24/7,
WDR
Continuous motion 24/7,
WDR
Continuous motion 24/7,
E-flip, Image stabilizer, WDR,
Auto-tracking
Axis part #
0257-004 0280-004 0220-004 0246-004 0274-004 0251-001 0253-001 0266-004
Part # Product Compatible with:
5015-101 AXIS T92A10 Housing
Aluminum construction - Indoor/outdoor
AXIS 210, AXIS 210A,
AXIS 211, AXIS 211A, AXIS 211M, AXIS 221, AXIS 223M
5010-001
AXIS T95A00 Dome Housing
1
Aluminum construction - Indoor/outdoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ
AXIS 231D+, AXIS 232D+, AXIS 233D
5010-631 AXIS T95A63 Extension Bracket Extension Bracket for AXIS T95A00 and T95A10 Dome Housing. Used with
AXIS T95A62 Ceiling / Parapet bracket.
5010-641 AXIS T95A64 Corner Bracket Requires AXIS T95A61 Wall Bracket.
5010-671 AXIS T95A67 Pole Bracket Requires AXIS T95A61 Wall Bracket.
5010-101
AXIS T95A10 Dome Housing
2
Aluminum construction - Indoor/outdoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ
AXIS 231D+, AXIS 232D+, AXIS 233D
24886
AXIS Indoor Fixed Wall Housing
3
AXIS 210, AXIS 210A,
AXIS 211, AXIS 211A, AXIS 221, AXIS 223M
24887
AXIS Indoor Fixed Corner Housing
3
24888
AXIS Indoor Fixed Ceiling Housing
3
21899 AXIS Indoor Fixed Housing
Aluminum construction - Indoor
AXIS 210, AXIS 210A,
AXIS 211, AXIS 211A, AXIS 221, AXIS 223M
22870 AXIS Indoor Fixed Camera Dome
Steel construction - Indoor
AXIS 210, AXIS 210A,
AXIS 211, AXIS 211A, AXIS 221, AXIS 223M
21898 AXIS Indoor Recessed Enclosure
Steel construction - Indoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ,
AXIS 231D+,AXIS 232D+, AXIS 233D
26549 AXIS 206/207 Ceiling-Mount Housing
Steel construction - Indoor
AXIS 206, AXIS 207 (not wireless)
26550 AXIS 206/207 Vandal-Resistant Housing
Aluminum construction - Indoor
AXIS 206, AXIS 207 (not wireless)
24889 AXIS Outdoor Fixed Housing
Aluminum construction - Outdoor
AXIS 211, AXIS 211A, AXIS 221, AXIS 223M
29892 AXIS Fixed Wireless Housing
Aluminum construction - Outdoor
AXIS 211W
25735 AXIS Pendant Dome Indoor
Plastic construction - Indoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ,
AXIS 231D+,AXIS 232D+, AXIS 233D
25733 AXIS Pendant Dome Outdoor
Plastic construction - Indoor/outdoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ,
AXIS 231D+, AXIS 232D+, AXIS 233D
25734 AXIS Pendant Vandal Dome
Aluminum construction - Indoor/outdoor
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ,
AXIS 231D+, AXIS 232D+
25736 Gooseneck Wall Mount Gooseneck wall mount for the AXIS Pendant Dome
25738 Parapet Mount Parapet mount for the AXIS Pendant Dome
22059 Corner Mount Adapter Corner mount adaptor for the AXIS Pendant Indoor, Outdoor, and
Vandal Dome Housings
21896 Pole Mount Adapter Pole mount adaptor for the AXIS Pendant Indoor, Outdoor, and Vandal
Dome Housings.
26349 Ceiling Mount 12” Extension Secures AXIS Pendant Dome housings to hard ceilings
26350 Ceiling Mount 24” Extension Secures AXIS Pendant Dome housings to hard ceilings
5500-381 AXIS 225FD Pendant Kit Connects AXIS 225FD to 25735, 25738, 26349, 26350, or 1-1/2 NPT
pipe
Axis pan/tilt/zoom network cameras
Axis network camera housings
www.axis.com OCTOBER 2008
Axis network camera housings
For more information, visit www.axis.com/products/video/accessories
1) Power supply included 2) Need PS-24 3) Steel construction - Indoor
