Rev. 1.00
- 11 -
BCD-1100
6. Switches
6-1 Display Switch
6-1-1 Feature : A Display Switch is located on the bottom of the display panel.
6-1-2 Function : Turns the power supply on/off.
6-2 DIP switches
6-2-1 Feature : Two DIP switches are located on the back of the display panel.
You can remove the DIP switch cover by pushing the hook.
6-2-2 Function: DIP switch settings can be read only when the power is on.
Therefore, any changes to the settings when the power is on do not take
effect.
6-2-3 DIP S/W #1 Function (RS-232 Serial Input Setting)
No. Function Switch OFF Switch ON
1 Default Setting DIP Switch Values EEP-ROM Data Leading
2 Reserved - -
3 Display Viewing Side Customer Side Operator Side
4 Self-test Execution Does not execute Executes
5~8 Emulation
5 6 7 8 Emulation 5 6 7 8 Emulation
0 0 0 0 Samsung VFD 1 0 0 0 NCR Real POS
0 0 0 1 Epson ESC/POS 1 0 0 1 PD6000
0 0 1 0 ADM787/788 1 0 1 0 ICD2002
0 0 1 1 DSP800 1 0 1 1 Reserved
0 1 0 0 AEDEX 1 1 0 0 Reserved
0 1 0 1 UTC Standard 1 1 0 1 Reserved
0 1 1 0 UTC Enhance 1 1 1 0 Reserved
0 1 1 1 CD5220 1 1 1 1 Reserved
(“0” : S/W OFF, “1” : S/W ON)
6-2-4 DIP S/W #2 Function (Command Emulation Mode and Self Test Setting)
No. Function Switch OFF Switch ON
1 Data Length 8 bits 7 bits
2 Parity using Non parity Parity
3 Parity Selection Odd Even
4~6 Transmit Speed
4 5 6 Transmit Speed 4 5 6 Transmit Speed
0 0 0 9,600 bps 1 0 0 115,200 bps
0 0 0 4,800 bps 1 0 1 57,600 bps
0 1 1 2,400 bps 1 1 0 38,400 bps
0 1 0 1,200 bps 1 1 1 19,200 bps
(“0” : S/W OFF, “1” : S/W ON)
7~8 Reserved - -
