7/3/2007
#20510
724-746-5500 blackbox.com
TECH SPECS
Controls — AC215A: Contrast, brightness, color, saturation, hue,
horizontal and vertical positioning;
AC217A: Input selection, output resolution, input to outputaspect
ratio conversion
Input Decoding — AC215A: 8-bit Y, 8-bit C, and 16-bit YUV with
comb-filter processing;
AC217A: 16-bit YUV with adaptive 4H comb-filter processing
Input Formats — Normal (4:3), Letterbox (16:9)
Input Types —AC215A: Composite and S-Video (Y/C), both terminating
into 75 ohms;
AC217A: Composite, S-Video, (Y/C), both terminating into 75 ohms,
component
Input Video Standards — AC215A: NTSC, NTSC-Japan, PAL (B, D, G, H, I,
M, N, N-3.58), SECAM;
AC217A: NTSC, PAL (B, G, H, I)
Output Resolutions — AC215A: 640 x 480, 800 x 600, 832 x 624, 852 x 480,
1024 x 768, 1280 x 1024 (60 Hz only);
AC217A: 480p, 720p, 1080p, 1280 x 1024, 1366 x 768
Aspect Ratio Conversion — AC217A: 4:3 to full screen, 4:3 to 4:3 in 16:9
screen, 16:9 to 16:9
Switch — AC217A: Selects output format for RGBHV, RGBS, or YCBCR
Connectors —
AC215A:
Input: (1) Composite: BNC F; S-Video: (1) 4-pin mini-DIN F;
Output: (1) HD15 F with standard VGA pinout, (5) BNC connectors
configurable as RGBHV, RGBS, or RGSB (RGB Sync on Green);
AC217A:
Input: (1) Composite: RCA F; S-Video: (1) 4-pin mini-DIN F;
Component: (3) RCA F;
Output: (1) HD15 F standard VGA pinout;
RS-232 remote: (1) 3-pin screw terminal
Power — AC215A: 95 to 250 VAC, 47 to 63 Hz, autosensing, external;
AC217A: 85 to 265 VAC, 47 to 63 Hz, autosensing, internal
Size — 1.5"H x 7.3"W x 8"D (3.8 x 18.5 x 20.3 cm)
Weight — AC215A: 3 lb. (1.4 kg);
AC217A: 2 lb. (0.9 kg)
Item Code
Advanced Video Scaler AC215A
Intelligent Video Scaler AC217A
For optimum performance and a 20% savings, order…
VGA Video Extension Cable
(Specify length, PVC or plenum construction, and gender
when ordering) EVNPS05
Recognize any of these situations?
• You wait more than 30 minutes to get through
to a vendor’s tech support.
• The so-called “tech” can’t help you or gives you
the wrong answer.
• You don’t have a purchase order number and the
tech refuses to help you.
• It’s 9 p. m. and you need help, but your vendor’s
tech support line is closed.
According to a survey by Data Communications
magazine, 90% of network managers surveyed say
that getting the technical support they need is extremely
important when choosing a vendor. But even though
network managers pay anywhere from 10 to 20% of their
overall purchase price for a basic service and support
contract, the technical support and service they receive falls
far short of their expectations—and certainly isn’t worth
what they paid.
At Black Box, we guarantee the best value and the
best support. You can even consult our Technical Support
Experts before you buy if you need help selecting just
the right component for your application.
Don’t waste time and money—call Black Box today.
Why Buy From Black Box? Exceptional Value.
Exceptional Tech Support. Period.
AC215A
