RS-232↔IEEE 488 INTERFACE CONVERTER
Figure 4-9. Setting the Internal DIP Shorting Jumper for RS-422.
The following illustrates the interface converter’s internal switch settings
for use with MacPlot, using the previously described format.
RS-422
RS-232
Shorting Plug
