Daewoo DVT-14/20H1(T)D TV VCR Combo User Manual



24
RN07 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN08 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RN09 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
RN10 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RN11 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN12 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN13 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN14 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RN15 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN16 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN17 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN18 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN19 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
RN20 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
RN21 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN24 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RN27 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN28 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN29 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RN31 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RN32 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RN33 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RN34 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RN35 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
RN36 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
RN37 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
RN38 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
RN39 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN40 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN41 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RN42 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN43 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN44 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
RN45 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RN46 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RN47 RD-AZ474J- R CARBON FILM 1/6 470K OHM J
RN48 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RN49 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RQ02 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
RQ03 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
RQ05 RN-AZ1001F R METAL FILM 1/6 1K OHM F
RQ06 RN-AZ1001F R METAL FILM 1/6 1K OHM F
RQ07 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
RQ08 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
RQ10 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
RQ11 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
RQ12 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
RQ13 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
RQ16 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
RQ18 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
RQ19 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
RQ20 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
RU01 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
RU02 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
RU05 RD-AZ201J- R CARBON FILM 1/6 200 OHM J
RU06 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
RU07 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
RU08 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RU09 RD-AZ512J- R CARBON FILM 1/6 5.1K OHM J
RU10 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
RU11 RD-AZ821J- R CARBON FILM 1/6 820 OHM J
RU12 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
RU13 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RU14 RD-AZ822J- R CARBON FILM 1/6 8.2K OHM J
RU15 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
RU16 RD-AZ334J- R CARBON FILM 1/6 330K OHM J
RU17 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
RU18 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
RU19 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RU20 RD-AZ229J- R CARBON FILM 1/6 2.2 OHM J
RU21 RD-AZ229J- R CARBON FILM 1/6 2.2 OHM J
RU22 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
RU23 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
RU24 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RU25 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RU26 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RU27 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RU28 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
RU29 RD-AZ433J- R CARBON FILM 1/6 43K OHM J
RU30 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RU31 RD-AZ225J- R CARBON FILM 1/6 2.2M OHM J
RU32 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
RU33 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RY01 RD-AZ243J- R CARBON FILM 1/6 24K OHM J
RY02 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY03 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
RY04 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RY05 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY06 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY07 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RY08 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RY09 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
RY10 RD-AZ201J- R CARBON FILM 1/6 200 OHM J
RY11 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
RY12 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
RY13 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
SERVICE PARTS LIST
