SpecificationsDX-15E220A12
Specifications
Specifications are subject to change without notice.
Warranty
Dimensions and weight
Screen
Display resolutions/VGA scan rates
Tuner
Inputs
Outputs
Audio
Power
Miscellaneous
DX-15E220A12
Parts: 1 year
Labor: 1 year
DX-15E220A12
Without stand:
15.83 x 1.50 x 10.91 in.
(40.2 x 3.8 x 27.7 cm)
With stand:
15.83 x 4.72 x 12.52 in.
(40.2 x 12 x 31.8 cm)
Without stand:
4.1 lbs. (1.86 kg)
With stand:
4.4 lbs. (2 kg)
DX-15E220A12
Screen size measured diagonally 15.6"
Display type LED
Panel 60 Hz vs.120 Hz 60Hz
Display resolution 720p
Panel resolution 1366 (H) × 768 (V)
Aspect ratio 16:9
Contrast ratio (typical)–panel 500:1
Dynamic contrast ratio–list value 3000:1
Brightness (center typical) cd/m2 140 nits
Comb filter 3d y/c digital
Response time 16 ms
Horizontal viewing angle 90
Vertical viewing angle 50
DX-15E220A12
HDMI 1.3 Suggested Resolutions:
1080p, 1080i, 720p,
480p, 480i
Component video Suggested Resolutions:
1080i, 720p, 480p, 480i
PC/VGA Suggested scan rates:
640× 480/60Hz,
800× 600/60Hz,
1024 × 768/60Hz,
1360 ×768/60Hz
DX-15E220A12
Analog NTSC
Digital ATSC, 8-VSB, Clear-QAM
DX-15E220A12
HDMI/DVI 2 (bottom)
E - E D ID c om p l i a nt
HDCP compliant
DVI to HDMI1 only
Component video 1 (side)
Composite video 1 (side)
Shared audio (component
and composite)
Yes
S-Video No
PC/VGA 1 (bottom)
3.5mm PC audio input 1 (bottom)
USB 1 (bottom)
Supports JPEG and
firmware upgrade
DX-15E220A12
Video No
Analog audio No
Digital audio 1 (side)
WiFi No
Ethernet No
Headphone 1 (side)
DX-15E220A12
Simulated Surround Sound No
Audyssey Dynamic Volume No
Sound Leveler No
Watts/Channel 3W
Number of Speakers 2
DX-15E220A12
Power consumption On: 18 W
Standby: <1 W
Power input 120V/60Hz
DX-15E220A12
OSD languages English, French, Spanish
INlink No
Game Mode No
ENERGY STAR qualified Yes
Internet connectable No
TV base screws B3 type (12 mm length)
(2 pcs)
V-Chip (version 2.0) Yes
Sleep timer Yes
Channel labeling Yes
VESA mount (mm)
(horizontal × vertical)
75 × 75
Note
The length of the wall-mount screws vary depending
on the wall-mount bracket you purchased. See the
instructions that came with the wall-mount bracket
for screw lengths.
