WE ARE GOING GREEN!
A copy of your User Guide is not
provided in the box but is available
online.
Go to www.dynexproducts.com,
click Support & Service. Enter your
model number in the Search eld,
then press Enter.
Click Support/Downloads.
One-year limited warranty
Visit www.dynexproducts.com for details.
Need additional help?
See your User Guide! This comprehensive guide
includes everything from basic how-to steps to
more advanced features. Go to
www.dynexproducts.com, click Support &
Service. Enter your model number in the Search
eld, then press Enter. Click Support/Downloads.
We’re here for you
www.dynexproducts.com
For customer service, call:
800-305-2204 (U.S./Canada markets)
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richeld, MN USA 55423-3645
© 2011 BBY Solutions, Inc., All Rights Reserved.
DYNEX is a trademark of BBY Solutions, Inc. Registered in some
countries. All other products and brand names are trademarks of
their respective owners.
ENGLISH 11-0313
Setup Wizard
Select
Move
EXIT
Exit
Next
English
Fran ais
ç
Espa
ñol
Choose Your Menu Language
MENU
Back
Set menu language to English, Fran ais, or Español.ç
Time
h
Savings
Setup Wizard
Next
Choose Your Time Setting
DST
Off
Auto
Time Zone
Pacific
Year
Month
2011
July
Day
Time
15
09 : 05 AM
Select
Move
EXIT
Exit
MENU
Back
IfAutomatic, options are automatically set byTVsource.
Mode
Setup Wizard
Next
Home Mode
Retail Mode
Choose Your Picture Mode
Select
Move
EXIT
Exit
MENU
Back
Reduces total power consumption.
Setup Wizard
Choose Your TV Source
Analog Channels
Digital Channels
0
0
Antenna
Cable
Cable/Satellite Box
RF CH : 0
Scan for channels
Select
Move
EXIT
Exit
MENU
Back
Select Antenna if using anantenna for standard or HDTV.
Setting up and using your remote control
1 Press the release button on the back of the remote to remove the battery compartment cover.
2 Insert two AAA batteries into the battery compartment. Make sure that the + and – symbols on
the batteries match the + and – symbols in the battery compartment.
3 Replace the cover.
Connecting power
Plug the AC power cord into the AC IN jack on the back of your TV,
then plug the other end of the cord into a power outlet.
Turning on your TV for the rst time
1 Connect the power cord to your TV and to a power outlet, then press (power).
The Choose Your Menu Language screen opens.
2 Press ▲ or ▼ to highlight a language, then press ENTER. The Choose Your Time Setting
screen opens with Mode highlighted.
3 Press ◄ or ► to select Auto or Manual. If you select Auto, the date and time are set
automatically from a digital TV signal. If you select Manual, you can manually set the
date and time. Press ENTER. The Choose Your Picture Mode screen opens.
4 Press ▲ or ▼ to highlight Home Mode or Retail Mode, then press ENTER. If you select
Retail Mode, a message asks you to conrm your selection. Select Yes or No. Retail
Mode is not an energy-saving mode. The Choose Your TV Source screen opens.
5 Press ▲ or ▼ to highlight Antenna, Cable, or Cable/Satellite box. If you select
Antenna or Cable, your TV scans for available channels. The scan may take several
minutes. If you select Cable/Satellite box, your TV does not scan for channels.
6 To watch TV, press TV on the remote control.
Programming your remote control
To program your universal remote control to work with your new Dynex TV, see the table for common codes. If you have problems programming your remote or need a dierent remote control code, visit http://www.dynexproducts.com/remotecodes for the
latest remote control code information.
46" LCD TV 1080p I QUICK SETUP GUIDE I DX46L261A12
Normal:
Displays the original 4:3 aspect ratio with black bars vertical on the left
and right hand side of the screen. If the original aspect ratio is 16:9, then
the image displays in 16:9.
Zoom:
Expands the image to ll the screen. The top and bottom of the image
may be cropped.
Wide:
Use this option to view content recorded in a 16:9 (wide-screen) aspect
ratio.
Cinema:
Stretches the image at the edges, but keeps a clear image in the center.
Auto:
Automatically adjusts the image based on the screen size and the TV
program.
Note: Auto is only available when Auto Zoom in the Channels menu is
set to On.
Aspect ratio options
CCD
Turns closed captioning on or o.
MTS/SAP
Cycles through mono, stereo, and
secondary audio for analog programs.
SLEEP
Sets the sleep timer.
ZOOM
Changes how the picture displays
on the screen.
Channel
Changes the TV channels.
EXIT
Closes the on-screen menu.
INFO
Opens a TV status banner.
RECALL
Returns to the previous channel.
Input
Opens the Input Source list.
GUIDE
Displays the program guide.
MUTE
Mutes the sound.
Selects the picture modes.
Quick Launch Inputs
Selects another source
connected to your TV.
CH-LIST
Opens the channel list.
Power
Turns your TV on or o.
ENTER
Conrms selections or changes.
MENU
Opens the on-screen menu.
Volume
Changes the volume.
Arrows
Navigates in on-screen menus.
.
Enter a digital sub-channel number.
(Example: 4.1)
Numbers
Enter channel numbers.
FAVORITE
Opens the Favorite Channel List.
AUDIO
Selects the audio modes.
Power outlet
Back of TV
Verizon
0198, 0490
Universal remote controls Cable/Satellite/Set-top box
Universal remote TV codes
TiVo
0091
Time WarnerDish Network
720
Cox
1326,
1463
DirectTV
10171, 11204, 11326,
11517, 11564, 11641,
11963, 12002
ComcastCharterCablevision
068, 069, 078, 096,
100, 164, 168, 229, 026
Sony
068, 069, 078, 096,
100, 164, 168, 229,
026
One for All
0054
RCA
135
Philips
0198, 0490
400, 450, 461,
456, 10463,
1463, 0463
10171, 11204, 11326,
11463, 11517, 11641,
11780, 11785, 11892,
11963, 12002
2002, 1204, 1423, 1517, 0171,
1963, 0463, 1463, 0842, 1326,
167, 415, 424, 450, 456, 461,
507, 523, 567, 577, 586
Power cord
