SLIMPROFILE TV MOUNT I QUICK SETUP GUIDE I DXTVM111
3-year limited warranty
Visit www.dynexproducts.com for details.
We’re here for you
www.dynexproducts.com
For customer service, call:
800-305-2204 (U.S./Canada markets)
01 800-926-3020 (Mexico market)
© 2010 BBY Solutions, Inc., All Rights Reserved.
Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue
South, Richeld, MN USA 55423-3645
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo
Piso, Colonia Cruz Manca, Programa Parcial de Desarrollo
Santa Fe, Delegación Cuajimalpa, Distrito Federal, México
05349
© 2010 Best Buy UK Distributions Limited. All rights reserved.
Distributed by Best Buy Europe Distributions Limited. 1 Portal
Way, London W3 6RS
DYNEX is a trademark of BBY Solutions, Inc. Registered in
some countries. All other products and brand names are
trademarks of their respective owners.
6907-002009 <00>
ENGLISH 10-0163
3 Mount the TV to the wall
Place the TV bracket into the slotted anges of the wall plate. The TV
can be mounted either (1) vertically or (2) with a 5-degree tilt.
4 Lock the TV to the wall plate
Slide the locking bar (C) through the TV bracket (B) and the wall plate (A) to
secure the TV. A padlock (not included) may be used for extra security.
HEAVY! You will need
assistance with this step.
5°
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
CAUTION: Do not use this product for any purpose not explicitly
specied by Dynex. Improper installation may cause property
damage or personal injury. If you do not understand these
directions, or have doubts about the safety of the installation,
contact Customer Service or call a qualied contractor. Dynex is
not responsible for damage or injury caused by incorrect
installation or use.
The weight of your TV must not exceed 30 lb (13.6 kg). The wall
must be capable of supporting ve times the weight of the TV
and wall mount combined.
This product contains small items that could be a choking hazard
if swallowed. Keep these items away from young children!
Vertical mount
Note: Attach the TV bracket to the ange that is closest to the wall plate.
Tilt mount
Note: Attach the TV bracket to the ange that is farthest from the wall plate.
Vertical mount Tilt mount
