Like all GE Security products, this Smart ConnectionCenter
Video Amplifier is a high quality
module designed to meet the needs of the most demanding applications. The Video Amplifier
takes inputs from CATV, Satellite TV, and off air signals and distributes them to any TV in the
home. In addition, Internal inputs provide the ability to re-distribute signals from components,
such as security cameras and other modulated sources, within the home to any other location.
This versatile module is broadband approved and has been tested for HDTV, digital and analog
TV. It provides the foundation for entertainment distribution in all Smart ConnectionCenter Pre-
mium Systems.
Key Features
CATV Input.
Supports satellite and CATV distribution
Auxiliary input for security cameras
Internal inputs for re-distribution of sig-
nals from DVDs and VCRs
High quality amplified outputs with 3 dB
gain
Dedicated Modem Output port.
Broadband and HDTV ready
Installation
Overview
This installation sheet describes the process for installing an RF Distribution Amplifier for Cable
and Satellite TV in the Smart ConnectionCenter. For more information on this Video Amplifier,
please refer to the product specifications provided on the back of this sheet.
Read all instructions carefully. Review tools and supplies list prior to installing the module.
Compatibility
The Video Amplifier is compatible with all Premium Smart ConnectionCenter models:
Can be included in all Premium Series Systems
Can be used with any camera.
Can be used for PAL or NTSC.
Can be used with any cable modem
Tools and Supplies
Pliers
CC-PS1300 12 VDC Power Supply 1.3 Amp. (not included)
CC-PD1000 Power Distribution Module (not included)
Torque Wrench Recommended
