PDP TV Service Manual
Hisense confidential
13
J5---XPR01
ITEM NAME FUNCTION
1 IR1 REMOTE CONTROL
2 GND
3 LED1 NO USED
4 LED2 NO USED
5 GND
6 5VST_BY POWER OF REMOTE
J7---XP7
ITEM NAME FUNCTION
1 CVBS1-IN SCART2 Y
2 GND
3 C-IN SCART2 C
4 GND
5 Y-IN SCART2 Y
6 GND
7 CVBS1-OUT NO USED
8 GND
9 CVBS2-OUT VIDEO OUT
10 GND
11 GPIO SCART1 SWITCH
J4---XP23
ITEM
NAME FUCTION
1 SC-G SCART1 GREEN SIGNAL
2 GND
3 SC-B SCART1 BULE SIGNAL
4 GND
5 SC-R SCART1 RED SIGNAL
6 GND
J22---XP22
ITEM
NAME FUCTION
1 SWI2 SCART2 SWITCH
2 GND
3 SC-FB SCART1 FAST BLANK
4 GND
