42
AV-32/28R4SK / LCT1567-001A-U / ENGLISH
Specifications
We may change the design and specifications without notice.
Pictures displayed on the screen using this TV’s ZOOM functions should not be shown for any
commercial or demonstration purpose in public places (cafes, hotels, etc.) without the consent of
the owners of copyright of the original picture sources, as this would be an infringement of
copyright.
Model
Item
AV-32R4SK AV-28R4SK
Broadcasting systems CCIR I
Colour systems PAL
• The EXT terminals also support the NTSC 3.58/4.43 MHz system.
Channels and frequencies E21-E69
Sound-multiplex systems NICAM (I) system
Teletext systems FLOF (Fastext),
WST (World Standard System)
Power requirements 220 - 240 V AC, 50 Hz
Power consumption 115 W (Standby: 2.7 W) 115 W (Standby: 2.7 W)
Picture tube size Viewable area 76 cm (measured
diagonally)
Viewable area 66 cm (measured
diagonally)
Audio output Rated Power output: 10 W + 10 W + 10 W + 18 W
Speakers TV: (13 cm × 6.5 cm) oval × 2, (16 cm × 4 cm) oval × 1
Subwoofer:13 cm round × 1
EXT-1 terminal Euroconnector (21-pin, SCART)
• Video input, Audio L/R inputs and RGB inputs are available.
• TV broadcast outputs (Video and Audio L/R) are available.
EXT-2 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input, Audio L/R inputs and RGB inputs are
available.
• Video and Audio L/R outputs are available.
• T-V LINK functions are available.
EXT-3 terminal Euroconnector (21-pin, SCART)
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
EXT-4 terminal RCA connectors × 3
• Video input and Audio L/R inputs are available.
AUDIO OUT terminal RCA connectors × 2
• Audio L/R outputs are available.
• Output level 0.5 Vrms.
SURROUND REAR terminal SPEAKER terminals for external surround speakers.
• Surround rear sounds are output to the speakers.
• For impedance 8-ohm speakers only.
• Rated power output: 7.5 W + 7.5 W
Headphone jack Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D) 948 mm × 562 mm × 554 mm 854 mm × 508 mm × 497 mm
Weight 56.0 kg 42.0 kg
Accessories Remote control unit × 1 (RM-C1502)
AA/R6 dry cell battery × 2
