SAFETY PRECAUTIONS
English
Recommended separation distance between portable and mobile RF commu-
nications equipment and the Model BD-X201MS
The Model BD-X201MS is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled.
The customer or the user of the Model BD-X201MS can help prevent electromagnetic interference by maintaining a minimum dis-
tance between portable and mobile RF communications equipment (transmitters) and the Model BD-X201MS as recommended
below, according to the maximum output power of the communications equipment.
Rated maximum output
power of transmitter
Separation distance according to frequency of transmitter (m)
W
150 kHz to 80 MHz
d =1.2 V
80 MHz to 800 MHz
d =1.2 V
800 MHz to 2.5 GHz
d =2.3 V
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can
be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of
the transmitter in watt (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
