DVD Premium Pro Series MICROBOARDS TECHNOLOGY, LLC
17
SETUP?
(MODE CHANGE)
Setup Menu
1. At the COPY START? (DISC to DISC) menu, press
the NO or ▼ button until the display shows SETUP?
(MODE CHANGE)
2. Press the YES button
3. The first setup option is Mode Select, followed by Copy DISC to HD/DISC, Write Speed,
ISRC Check, Copy Quantity, Session Mode, Drive Inquiry, Firmware Version and Exit.
4. Pressing the NO or ▼ button will allow you to move from menu to menu.
5. Pressing the YES button will allow you to view or change the configuration of the system.
Here is a description of each setup menu item:
Mode Select
COPY - Duplication from master disc to blank disc, or HDD to blank disc if master data is
registered.
VERIFY - It compares a copied disc with the master disc.
COPY+V - Copying in the COPY+VERIFY mode
DVD WR Speed
Available speeds range from 16x down to 1x.
CD WR Speed
Available speeds range from 48x down to 4x.
ISRC Check
Default setting is ON. This feature will copy the ISRC codes from the Master audio disc to the
blank discs.
Auto Run
Default setting is OFF. When set to ON, this allows the duplicator to start the duplication process
when all recorders are loaded with blank media. If you are copying Disc-to-Disc, the master must
be loaded before duplication will begin.
Copy Quantity
Set up the number of disc you want to copy.
Use the ▼▲buttons to change the number in the current column up or down. YES will move you
one column to the right, NO will move you 1 column to the left. Press YES when in the right
column to save the number of copies entered. The example above shows that 750 copies have
been entered with the cursor currently in the right column (underlined).
Session Mode (CD only. Invalid for DVD)
Select either from AUTO, CLOSE, or OPEN.
AUTO: Make the session of copied disc as same as the master.
CLOSE: Close the session of copied disc.
OPEN: Leave the session of copied disc open.
Reader Select
Changes which drive is selected as the reader. This setting should not be changed.
Drive Inquiry
Displays an inquiry of each drive connected, showing drive model and firmware.
F/W Version
Shows DVD Premium Pro Series firmware version and H/W information.
F/W Update
Used when updating the firmware of the DVD Premium Pro Series duplicator.
NET Reboot
Will reboot the Master tower and any towers Slaved to the Master when running using the NET
option. This menu item is not available when running in Stand Alone mode.
Log
Displays the number of successful and unsuccessful discs over the entire life of the duplicator.
>>COPY QUANTITY
0750
