INTRODUCTION
Remote Control
Remote Control Operation Range
Point the remote control at the remote sensor and press
the buttons.
Distance: About 23 ft (7 m) from the front of the
remote sensor
Angle: About 30° in each direction of the front of the
remote sensor
Remote control battery installation
Detach the battery cover on the rear of
the remote control, and insert two R03
(size AAA) batteries with and
aligned correctly.
Caution
Do not mix old and new batteries. Never
mix different types of batteries (stan-
dard, alkaline, etc.).
CLEAR PROGRAM
DISPLAY
RETURN
SELECT
ENTER
TITLE MENU
AUDIO SUBTITLE SOUNDANGLE
SETUP REPEAT RANDOM
POWER OPEN/CLOSE
A-B
123
45
6
7
8
0
9
SLOW
ZOOM MARKER — SEARCH
PAUSE/STEP
NEXT DISC
STOP
PLAY
SCAN SKIP
POWER
Switches DVD Player ON and OFF.
SETUP •
Accesses or removes setup menu.
REPEAT •
Repeat chapter, track, title, all.
A-B •
Repeat sequence.
RANDOM •
Plays tracks in random order.
TITLE
Displays the discs Title menu, if
available.
11 22 33 44
(left/right/up/down)
Selects an item in the menu.
DISPLAY
Accesses On-Screen display
ZOOM •
Enlarges video image.
MARKER •
Marks any point during playback.
SEARCH •
Displays MARKER SEARCH menu.
NEXT DISC •
Moves to the next available disc tray.
PAUSE/STEP (
;;
) •
Pauses playback temporarily/ press
repeatedly for frame-by-frame
playback.
Reverse SLOW (
,,
) •
Reverse slow playback.
Forward SLOW (
..
) •
Forward slow playback.
CLEAR
Removes a track number on the
program menu or a mark on the
MARKER SEARCH menu.
OPEN/CLOSE
Opens and closes the disc tray.
• AUDIO
Selects an audio language (DVD) or
an audio channel (CD).
• SUBTITLE
Selects a subtitle language.
• ANGLE
Selects a DVD camera angle if
available.
• SOUND
Selects sound mode during disc
playback.
MENU
Accesses menu on a DVD disc.
SELECT/ENTER
Acknowledges menu selection.
RETURN
- Removes the setup menu.
- Displays the menu of a video CD
with PBC.
• SCAN (
QQ
/
RR
)
Press for fast reverse search or for-
ward search.
• PLAY (
22
)
Starts playback.
• STOP (
99
)
Stops playback.
• SKIP (
SS
/
TT
)
Moves to PREVIOUS or NEXT
chapter/track.
0-9 number buttons
Selects numbered items in a menu.
PROGRAM
Accesses or removes program menu.
