NEC 61XM2/S Flat Panel Television User Manual



just one look.
Re-energize your eyes while being captivated by NEC's PlasmaSync
residential plasma displays. The image is so powerful and engaging you
wont’ believe what you are seeing. Engineered to be the definitive multimedia
home theater, the PlasmaSync residential plasma displays provide superior
image quality, realistic colors, broad compatibility, flexible connections and
built in stereo-audio. Simply put, they can place your programs center stage
and keep you on the edge of your seat.
superior image quality.
Designed specifically for residential use, the PlasmaSync combines true HDTV
resolution
and NEC’s outstanding image quality to give you the definitive tool
for watching images with power and clarity. Our exclusive
Capsulated Color
Filter technology
provides extremely realistic and saturated colors as well as
enhanced contrast. Color realism is enhanced by
AccuCrimson, a filter
technology that produces the purest shade of red possible in a plasma display.
NEC’s
Advanced AccuBlend scan conversion provides precise interpolation
of information ranging from video, HD and PC signals in
multiple aspect ratio
modes.
This enables the plasma to display clear, readable images even in
non-native resolutions.
And
AccuShield phosphor protection system helps your screen stay
protected from image retention with the most comprehensive set of built-in
modes including programmable Orbiter, Inverse RGB, All-White, Pixel
Refresh, Brightness Limiter and Soft Focus.
PlasmaSync
®
42XM2/S, 50XM3/S, 61XM2/S. Residential displays.
Imagine a flawless reproduction of your favorite view as you sit back in your most
comfortable chair. NEC’s PlasmaSync residential displays deliver vivid colors and
absolute clarity for pure enjoyment.
It’s inspiring.
Specifications
Model Number PX-42XM2A/S Diagonal Screen Size 42"
PX-50XM3A/S Diagonal Screen Size 50"
PX-61XM2PA/S Diagonal Screen Size 61"
Screen Aspect Ratio 16 to 9
Active Screen Area
42XM2/S 36.3 in x 20.4 in, 921mm x 518 mm
50XM3/S 43.5 in x 24.5 in, 1106 mm x 622 mm
61XM2/S 53.2 in x 29.9 in, 1351 mm x 760 mm
Native Pixel Resolution
42XM2/S at 1024 x 768
50XM3/S and 61XM2/S 1365 x 768
Pixel Pitch
42XM2/S 0.897mm x 0.675mm
50XM3/S 0.81mm x 0.81mm
61XM2/S 0.99mm x 0.99mm
Capsulated Color Filter Yes
Accucrimson Yes
Front Filter Type AR - Anti reflection
Color Processing (4096 Steps) 68.7 billion colors
Viewing Angle 160 degrees
Horizontal Frequency Range 15.5 to 110.0 kHz auto, step scan
Vertical Frequency Range 50 to120 Hz auto, step scan
Video Signal Compatibility PAL, SECAM, 3.58/4.43 NTSC
HD Video Signal Compatibility 480p 480i, 525p, 525i, 540p, 625p, 625i, 720p,1035i, 1080i
PC Signal Compatiblity VGA 640x480 @ 60,72,75,85,100, 120 Hz , SVGA 800x600 @ 56, 60, 72,75,85,100,120 Hz, XGA 1024x768 @ 60,70,75, 85, 100 Hz, SXGA 1280x1024 @ 60, 75, 85, 100 Hz ,
UXGA 1600x1200 @ 60, 65, 70, 75, 85 Hz, WideVGA 848x480, 852 x 480 @ 60 Hz, WideXGA 1360 x 765 @60 Hz, 1280 x 768 @ 60Hz
Macintosh Compatibility 640x480, 832x624, 1024x768, 1152x870
Input/Output Terminals Video 1 Composite BNC x 1 (common use with Video out, selectable)
Video 2 Composite RCA x 1
Video 3 S-Video 4-Pin DIN
HD Video 1 1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr)
HD Video 2 1 set BNC Component (Y,Pb,Pr/Y,Cb,Cr) (common use with 5BNC Y/Pb/Pr input,selectable)
RGB 1 (analog) 15-pin mini D-sub (common use with RGB out, selectable)
RGB 2 (analog) 5 BNC (RGB/HV) (common use with 5BNC Y/Pb/Pr input, selectable)
RGB 3 (digital) 24-pin DVI-D HDCP (EIA/CEA-861-A) compatible
Audio 3 sets RCA stereo + external speaker jacks
Audio
50XM3/S and 61XM2/S Internal amplifier, 9W x 2 output power
42XM2/S Internal amplifier, 8W x 2 output power
External Control 9-pin mini D-Sub, RS232
User Controls Direct Access Power on/off, input selection, volume up/down, OSM access
Remote Control Power on/off, input select, volume, mute, wide, display, off-timer, OSM control, cursor, pointer, zoom, auto, select
OSM Picture - Contrast, brightness, sharpness, color, tint, color temperature, white balance, picture mode, noise reduction, gamma, low tone and color tune
Audio - bass, treble, balance and audio input
Image Adjust - aspect ratio mode, vertical position, horizontal position, vertical height, horizontal width, fine picture, picture adjust, auto picture
Option 1 - OSM on/off, BNC Input, D-sub Input, RGB select, HD select, Input Skip, All Reset
Option 2 - Pwr. Management, Cinema Mode, Long Life Mode
Option 3 - Timer, Pwr. On mode, Control Lock, IR Remote, Loop Out, ID Number, Video Wall Advanced OSM, Language, Color System, Source Information
Power Requirements 120V 50/60 Hz
Power Consumption
42XM2/S 350W Typical, 4.6 Amp Maximum
50XM3/S 480W Typical, 6.9 Amp Maximum
61XM2/S 540W Typical, 6.7 Amp Maximum
Standby Power 0.9W
Dimensions (WxHxD)-w/out base
42XM2/S 1018 x 610 x 89mm, 40.1 x 24.0 x 3.5 inches
50XM3/S 1222 x 736 x 96mm, 48.1 x 29.0 x 3.8 inches
61XM2/S 1470 x 880 x 119 mm, 57.9 x 34.6 x 4.7 inches
Weight
42XM2/S 29.5 kg, 65.0 lbs. (without tabletop stand)
50XM3/S 43.8 kg, 96.4 lbs. (without tabletop stand)
61XM2/S 61.0 kg, 134.2 lbs. (without tabletop stand)
Environmental Considerations Operating Temperature 32 - 104 degrees F (0 - 40 degrees C)
Operating Humidity 20 - 80%
Operating Altitude 0 - 9180 feet (0 - 2800m)
Storage Temperature 14 - 122 degrees F (-10 - 50 degrees C)
Storage Humidity 10 - 90%
Storage Altitude 0 to 9840 feet (0 - 3000m)
Regulatory FCC part 15 Classs B, ANSI C63.4-1992, UL6500 Second Edition, CAN/CSA-E60065-00, UL60950 Third Edition, CSA C22.2 No.60950
Included Accessories AC Power Cord, User Manual, Remote Control, Batteries, Cable Clamps
Optional Accessories Tabletop Stand
42XM2/S: PX-ST1U/S 50XM3/S: PX-ST1U/S 61XM2/S: PX 61ST1U/S
Attachable Speakers
42XM2/S: PX42PSP1US 50XM3/S: PX-50SP1U/S 61XM2/S: PX-61SP1U/S
Input Terminal Cover
42XM2/S: PX-CV1U 50XM3/S: PX-CV1U 61XM2/S: PX-CV2U
Fixed Wall Mount
42XM2/S: FWMK 50XM3/S: FWMK 61XM2/S: 61FWMK-1
Tilt Wall Mount
42XM2/S: TWMK 50XM3/S: TWMK 61XM2/S: 61TWMK-1
Ceiling Mount 42XM2/S: CMK 50XM3/S: CMK 61XM2/S: 61CMK
true HDTV resolution
Capsulated Color Filter™ technology
AccuCrimson™
Advanced AccuBlend™
multiple aspect ratio control
AccuShield™ phosphor protection
For more information, call (800) NEC-INFO
or visit www.necvisualsystems.com
NEC is a registered trademark of NEC Corporation.
All other trademarks are the property of their respective owners.
All specifications subject to change without notice.
NEC Solutions (America), Inc.
Visual Systems Division
1250 Arlington Heights Rd., Suite 400
Itasca, IL 60143-1248
NEC 120304
42XM2/S 36.3” (921mm)
50XM3/S 43.5” (1106mm)
61XM2/S 53.2” (1351mm)
42XM2/S 20.4” (518mm)
50XM3/S 24.5” (622mm)
61XM2/S 29.9” (760mm)
42XM2/S 24.0” (610mm)
50XM3/S 29.0” (736mm)
61XM2/S 34.6” (880mm)
42XM2/S 3.5” (89mm)
50XM3/S 3.8” (96mm)
61XM2/S 4.7” (119mm)
42XM2/S
40.1” (1018mm)
50XM3/S 48.1” (1222mm)
61XM2/S 57.9” (1470mm)
