Specifications
Screen Size 36.3"(H)ן20.4"(V) inches
921(H)ן518(V) mm
diagonal 42"
42VP4PA: Installed AR (Anti-Reflection) Filter
42VP4DP-A: Installed AG (Anti-Glare) Filter
Aspect Ratio 16 : 9
Resolution 853(H)ן480(V) pixels
Pixel Pitch 0.04"(H)ן0.04"(V) inches
1.08(H)ן1.08(V) mm
Color Reproduction 256 levels, 16,770,000 colors
Signals
Synchronization Range Horizontal : 15.5 to 110 kHz
(automatic : step scan)
Vertical : 50.0 to 120 Hz
(automatic : step scan)
Input Signals RGB, NTSC (3.58/4.43), PAL (B,G,M,N),
PAL60, SECAM, HD*
1
, DVD*
1
, DTV*
1
Input Terminals (VIDEO1 and RGB1 can also be used as OUTPUT terminals)
RGB
Visual 1 (Analog) mini D-sub 15-pinן1
Visual 2 (Analog) BNC (R, G, B, H/CS, V)ן1*
2
Visual 3 (Digital) DVI-I 24-pinן1*
3
Video
Visual 1 BNCן1
Visual 2 RCA-pinן1
Visual 3 S-Video: DIN 4-pinן1
DVD/HD/DTV
Visual 1 RCA-pin (Y, PB[CB], PR[CR])ן1*
1
Visual 2 BNC (Y, PB[CB], PR[CR])ן1*
1,
*
2
Audio Stereo RCAן3(Selectable)
External Control D-sub 9-pinן1(RS-232C)
Sound output 8W+8W at 6 ohm
Power Supply AC120V 50/60Hz
Current Rating 3.7A (maximum)
Power Consumption 270W (typical)
Dimensions 40 (W)ן24 (H)ן3.5 (D) inches
1018 (W)ן610 (H)ן89(D) mm
Weight 62.8 lbs / 28.5 kg (without stand)
Environmental Considerations
Operating Temperature 0°C to 40°C / 32°F to 104°F
Humidity 20 to 80% (no condensation)
Altitude 0 to 9180 feet / 0 to 2800 m
Storage Temperature -10°C to 50°C / 14°F to 122°F
Humidity 10 to 90% (no condensation)
Altitude 0 to 9840 feet / 0 to 3000 m
Front Panel User Controls Power on/off, Input source select,
Volume up/down, OSM control
Remote Control Functions
Power on/off, Input source select, OSM
control,Volume up/down, Cursor (UP,
DOWN,LEFT, RIGHT), Pointer, Zoom up/
down, Off timer, Wireless/Wired remote
control
OSM Functions
Picture (Contrast/Brightness/Sharpness/ Color/Tint/
Picture mode/Noise reduction/Color temperature/
White balance/Gamma/Low tone/Color tune), Audio
(Bass/Treble/Balance/Audio input), Image Adjust
(Aspect mode/V-Position /H-Position/V-Height /H-
Width/Auto Picture/Fine picture/Picture adjustment),
Option1 (OSM/BNC Input/D-Sub Input/RGB Select/
HD Select/Input Skip/All Reset), Option2 (Power
management/Cinema mode/Long life [PLE, Orbiter,
Inverse, White, Screen wiper, Soft focus]/Gray level/
S1/S2), Option3 (Timer/Power on mode/Control lock/
IR Remote/Loop out/ID number/Video wall [Divider,
Position, Disp. mode, Auto ID, Image adjust, Power
on delay, PLE link, Timer]), Advanced OSM,
Language*, Color system, Source information
*English, German, French, Italian, Spanish, Swedish,
Chinese
The features and specifications may be subject to change without
notice.
*
1
HD/DVD/DTV input signals supported on this
system
480P (60 Hz) 480I (60 Hz)
525P (60 Hz) 525I (60 Hz)
576P (50 Hz) 576I (50 Hz)
625P (50 Hz) 625I (50 Hz)
720P (60 Hz) 1035I (60 Hz)
1080I (50 Hz) 1080I (60 Hz)
*
2
The 5-BNC connectors are used as RGB/PC2 and
HD/DVD2 input. Select one of them under “BNC
INPUT”.
*
3
Not compatable with HDCP.
Units are in inch
(mm)
3.5"
(89)
1.18"
(30)
2.32"
(59)
40" (1018)
24" (610)
36.3" (921)
20.4" (518)
Other Features Motion compensated 3D Scan Converter (NTSC,
PAL, 480I, 576I, 525I, 625I, 1035I, 1080I), 2-3
pull down Converter (NTSC, 480I, 525I, 1035I,
1080I (60Hz)), 2-2 pull down Converter (PAL,
576I, 625I, NTSC, 480I, 525I), Digital Zoom
Function (100-900% Selectable), Video Wall 2×2/
3×3 multi screen, Self Diagnosis, Anti Image
Burn (PLE LOCK1~3, INVERSE, WHITE,
ORBITER (Auto1,2/Manual), SCREEN WIPER),
Color Temperature select (high/mid/mid low/low,
user has 4 memories), Control lock (Except power
SW), Auto Picture, Input Skip, Color Tune, Low
Tone (3 mode), Auto ID, Programmable Timer,
Gamma Correction (4 mode), Loop through
interface, Plug and play (DDC1, DDC2b, RGB3:
DDC2b only)
Accessories Remote control with two AAA batteries, Power
cord, Manuals, Safety metal fitting parts, Ferrite
cores, Bands
Regulations UL Approved (UL 60950/CSA C22.2
No.60950-00)
DOC Canada requirements
Meets FCC Class A requirements
Ⅵ 42VP4PA/42VP4DP-A
