5 Then enter the code noted in step 2 using the digital keys.
– The TV key will now flash twice.
If the key flashes once for an extended period, the code has not been
entered properly or the wrong code has been entered.
Start again from step 2.
6 Point the SRU 5030 at the TV and check that it responds as it should.
– If the TV responds to all of the key commands,the SRU 5030 is ready
for use. Do not forget to note your code.
• If the device does not respond at all,or not to all of the
key commands,start again from step 2 and try the next code
from the list.
3. Keys and functions
The illustration on page 3 gives an overview of all keys and their functions.
1 y Standby. . . . . . . . . switches TV,VCR or DVD on or off.
2 . . . - teletext on/off ( );
- text mix ( );
- text off ( );
- wide screen TV ( );
- enlarge ( );
- text hold ( ).
3 MENU . . . . . . . . . . . . turns the menu on and off.
4 Cursor keys. . . . . . . cursor up, down, left,right in a menu.
5 A/V . . . . . . . . . . . . . . . switches between external inputs of your
equipment.
6 s . . . . . . . . . . . . . . . . . mutes the sound of the TV.
7 - VOL + . . . . . . . . . . . adjusts the TV volume.
8 Digit keys. . . . . . . . . direct choice of channels and other functions.
9 SHIFT . . . . . . . . . . . . for extra functions.When pressed at the same
time as a second key, the second key will get
another function.All blue labelled keys can be used
together with SHIFT. For example:
SHIFT + INSTALLinstalls your TV
SHIFT + STORE. . stores TV settings
Try out other combinations with the SHIFT-key on your device in order to
find out which functions are available.
Only functions featured on the original remote control are available.
0 5. . . . . . . . . . . . . . . . . - red teletext key
- rewind (VCR/DVD)
2 . . . . . . . . . . . . . . . . . - index
- play (VCR/DVD)
6. . . . . . . . . . . . . . . . . - blue teletext key
- wind (VCR/DVD)
9 . . . . . . . . . . . . . . . . . - green teletext key
- stop (VCR/DVD)
0 . . . . . . . . . . . . . . . . . record
;. . . . . . . . . . . . . . . . . . - yellow teletext key
- pause (VCR/DVD)
7
