Now, whenever you press
VOL +, VOL - or MUTE your Cable
Converter or VCR will control the
volume.
To change the Volume Lock setting on
the
One For All Access 4
so each
mode controls its own volume:
1. Press and hold SETUP until
the
One For All Access 4’s
red light blinks twice, then
release SETUP.
2. Press 9 - 9 - 3. The
One For
All Access 4’s
red light will
blink twice.
3. Press and release VOL +.
The
One For All Access 4’s
red light will blink twice.
Now, whenever you press
VOL +, VOL - or MUTE on the
One For
All Access 4
each component will
control its own volume.
Re-Assigning Device
Keys
You can use the
One For All Access 4
to operate a second TV or a second
VCR or any combination of four home
entertainment components. For
example, you may want your
One For
All Access 4
to control 1 TV, 1 Cable
Converter and 2 VCRs. To accomplish
this, you must re-assign the AUX key
to operate the desired component, in
this case, a second VCR. The chart
below shows you how to re-assign a
particular device key and then set up
your new component.
TV to VCR SETUP* + 992 + VCR +
TV + TV + SETUP* +
VCR code.
TV to CBL SETUP* + 992 + CBL +
TV + TV + SETUP* +
Cable/DBS code.
VCR to TV SETUP* + 992 + TV +
VCR + VCR + SETUP*
+ TV code.
VCR to CBL SETUP* + 992 + CBL +
VCR + VCR + SETUP*
+ Cable/DBS code.
CBL to TV SETUP* + 992 + TV +
CBL + CBL + SETUP*
+ TV code.
CBL to VCR SETUP* + 992 + VCR +
CBL + CBL + SETUP*
+ VCR code.
AUX to TV SETUP* + 992 + TV +
AUX + AUX + SETUP*
+ TV code.
AUX to VCR SETUP* + 992 + VCR +
AUX + AUX + SETUP*
+ VCR code.
AUX to CBL SETUP* + 992 + CBL +
AUX + AUX + SETUP*
+ Cable/DBS code.
*NOTE: Here you must hold
SETUP
until the One For All Access 4’s red
light blinks twice.
Volume Lock
Volume Lock allows the user to
designate which component will control
the volume in the TV, VCR and CBL
modes. To set the Volume Lock to the
TV mode:
1. Press and hold SETUP until
the
One For All Access 4’s
red light blinks twice, then
release SETUP.
2. Press 9 - 9 - 3. The One For
All Access 4’s red light will
blink twice.
3. Press and release TV. The
One For All Access 4’s red
light will blink twice.
Now, whenever you press
VOL +, VOL - or MUTE in the VCR or
CBL mode your TV will control the
volume.
To change the Volume Lock setting on
the
One For All Access 4
to the VCR or
CABLE mode:
1. Press and hold SETUP until
the
One For All Access 4’s
red light blinks twice, then
release SETUP.
2. Press 9 - 9 - 3. The
One For
All Access 4’s
red light will
blink twice.
3. Press and release CBL or
VCR. The
One For All
Access 4’s
red light will blink
twice.
S
E
T
U
P
9-9-3
9-9-3
S
E
T
U
P
CBL
VCR
9-9-3
9-9-3
VOL +
One For All
®
PRODUCTS
Limited Warranty
One For All (“OFA”) warrants, to the original purchaser only, that this product will be
free from defects in materials and workmanship, under normal use, for ninety (90)
days from the date of original purchase.
This warranty does not cover damage or failures caused by products or services not
supplied by OFA, or which result from accident, misuse, abuse, neglect, mishandling,
misapplication, faulty installation, set-up adjustment, improper maintenance, alteration,
maladjustment of consumer controls, modifications, commercial use, or that is attrib-
utable to acts of God.
There are no express warranties except as listed above. OFA SHALL NOT BE LI-
ABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
TO THE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the
exclusion or limitation of incidental or consequential damages, or limitations on how
long an implied warranty lasts, so the above exclusions or limitations may not apply to
you. This warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
To obtain warranty service for a defective product during the warranty period, please
return the product, preferably in the original carton, along with your purchase receipt,
to the store of original purchase. A note detailing the complaint would be helpful. The
store, at its option, will replace or repair this product if found to be defective.
One For All
(330) 405-8655
One For All
®
is a trademark of Universal Electronics Inc.
Copyright 1998 by Universal Electronics Inc. No part of this publication may be repro-
duced, transmitted, transcribed, stored in any retrieval system, or translated to any
language, in any form or by any means, electronic, mechanical, magnetic, optical,
manual, or otherwise, without the prior written permission of Universal Electronics Inc.
S
E
T
U
P
9-9-3
9-9-3
TV
URC-4700 - One For All Access 4 With Glow Key
Replace the batteries
with four (4) new AAA
alkaline batteries.
Make sure you press
the device key first, then
aim your
One For All
Access 3
at your home
entertainment
component. Also make
sure that you are within
15 feet of the
component you are
trying to operate before
using your remote.
Try all of the codes
listed for your brand of
home entertainment
component in the
“SETUP CODES”
section. Many setup
codes may allow for
partial functionality,
however, only one set
up code will operate
your home entertain-
ment component
correctly. Make sure all
of the components
that you are setting up
can be operated with
an infrared remote
control.
Use the VCR set-up
codes for your brand.
Some combo units,
however, may require
both a TV code to
control volume and a
VCR code for the
remaining functions.
As a safety feature on
the
One For All Access
4
, you must press the
REC key twice.
Due to RCA design
(1983-1987), only the
original remote control
will operate these
functions.
If your original remote
control required an
ENTER keystroke when
changing channels,
press the ENTER key
on the
One For All
Access 4
after you enter
the channel number.
Press and hold SETUP
until the
One For All
Access 4’s
red light
blinks twice. Release
SETUP and enter
9-8-7.
Red light not
blinking when
you press a
key?
The red light
blinks when you
press a key but
you receive no
response from
your home
entertainment
component?
The
One For All
Access 4
does
not operate your
home
entertainment
components or
is not
performing
commands
properly?
Problems
programming a
TV/VCR
combo?
VCR not
recording?
CH▲/▼
(Channel
Up/Down) and
RECALL not
working for your
RCA TV?
Problems
changing
channels?
Keypad
scrambled?
Trouble Shooting
Problem Solution
World Wide Web:
http://www.oneforall.com
This One For All
®
product is designed for compatibility in North America
excluding Mexico.
