Model Number TH-65PZ700A TH-58PZ700A TH-50PZ700A TH-42PZ700A
Diagonal Screen Size
65”/165cm 58”/147cm 50” /127cm 42”/106cm
Screen Aspect Ratio 16:9 Widescreen 16:9 Widescreen 16:9 Widescreen 16:9 Widescreen
Screen Display Type G10 Progressive Scan FHD (1920x1080) Plasma Display G10 Progressive Scan FHD (1920x1080) Plasma Display G10 Progressive Scan FHD (1920x1080) Plasma Display G10 Progressive Scan FHD (1920x1080) Plasma Display
Anti-Glare Filter
Yes Yes Yes Yes
Contrast Ratio (in dark surroundings)
10,000:1 10,000:1 5,000:1 5,000:1
Displayable Colours
Max 68.7 billion viewable colours Max 68.7 billion viewable colours Max 68.7 billion viewable colours Max 68.7 billion viewable colours
Shades of Gradation
4096 equivalent steps of gradation 4096 equivalent steps of gradation 4096 equivalent steps of gradation 4096 equivalent steps of gradation
Picture Enhancements
3D Colour Management, Colour Balance, Picture Sharpness Control,
Sub-Pixel Control, MPEG Noise Reduction, C.A.T.S (Contrast Automatic
Tracking System)
3D Colour Management, Colour Balance, Picture Sharpness Control,
Sub-Pixel Control, MPEG Noise Reduction, C.A.T.S (Contrast Automatic
Tracking System)
3D Colour Management, Colour Balance, Picture Sharpness Control,
Sub-Pixel Control, MPEG Noise Reduction, C.A.T.S (Contrast Automatic
Tracking System)
3D Colour Management, Colour Balance, Picture Sharpness Control,
Sub-Pixel Control, MPEG Noise Reduction, C.A.T.S (Contrast Automatic
Tracking System)
Picture Viewing Modes Dynamic, Normal, Cinema, Auto Dynamic, Normal, Cinema, Auto Dynamic, Normal, Cinema, Auto Dynamic, Normal, Cinema, Auto
Component (YPbPr)/HDMI Video Input Formats
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(50/60Hz) HDMI only.
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(50/60Hz) HDMI only.
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(50/60Hz) HDMI only.
480i/480p(60Hz); 576i/576p(50Hz); 720p(50/60Hz); 1080i(50/60Hz);
1080p(50/60Hz) HDMI only.
PC Video Input Signals (VGA 15 Pin D-Sub)
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz;
832x624@75Hz; 852x480@60Hz; 1024x768@60/70/75/85Hz;
1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz;
832x624@75Hz; 852x480@60Hz; 1024x768@60/70/75/85Hz;
1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz;
832x624@75Hz; 852x480@60Hz; 1024x768@60/70/75/85Hz;
1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
640x400@70Hz; 640x480@60/66/75Hz; 800x600@60/75/85Hz;
832x624@75Hz; 852x480@60Hz; 1024x768@60/70/75/85Hz;
1152x870@75Hz; 1280x1024@60Hz; 1366x768@60Hz
PC Video Adjustment Controls
Red&Blue White Balance, Gamma, H-Position, V-Position,
Video Sync:H&V/SOG
Red&Blue White Balance, Gamma, H-Position, V-Position,
Video Sync:H&V/SOG
Red&Blue White Balance, Gamma, H-Position, V-Position,
Video Sync:H&V/SOG
Red&Blue White Balance, Gamma, H-Position, V-Position,
Video Sync:H&V/SOG
Aspect Ratio Control
16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV 16:9;
PC 16:9 & 4:3
16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV 16:9;
PC 16:9 & 4:3
16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV 16:9;
PC 16:9 & 4:3
16:9, 14:9, Just, 4:3, 4:3 Full, Zoom1, Zoom2, Zoom3; DTV 16:9;
PC 16:9 & 4:3
Digital TV Tuner
Integrated SD/HD DTV Tuner
Yes Yes Yes Yes
DTV System
DVB-T DVB-T DVB-T DVB-T
Tuning Channel Plan
7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia
DTV Video
MPEG2 SD/HD MPEG2 SD/HD MPEG2 SD/HD MPEG2 SD/HD
DTV Audio
Dolby Digital/MPEG1-L2 Dolby Digital/MPEG1-L2 Dolby Digital/MPEG1-L2 Dolby Digital/MPEG1-L2
DTV Features (*when broadcast)
7 Day Electronic Program Guide (EPG)*; Now & Next program Informa-
tion*; Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
7 Day Electronic Program Guide (EPG)*; Now & Next program Informa-
tion*; Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
7 Day Electronic Program Guide (EPG)*; Now & Next program Informa-
tion*; Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
7 Day Electronic Program Guide (EPG)*; Now & Next program Informa-
tion*; Teletext Sub-titles*; 4x user defined DTV Favourite Channel lists
Analogue TV
Tuner
Integrated Analogue Tuner
Yes Yes Yes Yes
Analogue TV System PAL B/G PAL B/G PAL B/G PAL B/G
Tuning Channel Plan 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia 7MHz VHF/UHF Australia
CATV Compatibility
Hyper-band Hyper-band Hyper-band Hyper-band
Stereo Reception
German 2CS (A2) German 2CS (A2) German 2CS (A2) German 2CS (A2)
Teletext
2000p Level 2.5 Fasttext/List/Top 2000p Level 2.5 Fasttext/List/Top 2000p Level 2.5 Fasttext/List/Top 2000p Level 2.5 Fasttext/List/Top
Sound
Advanced Smart Sound Speaker System
Yes Yes Yes Yes
Speakers
2x100mm Woofer; 2 x (23mm x 100mm) Tweeter 2x80mm Woofer; 2 x (23mm x 100mm) Tweeter 2x80mm Woofer; 2 x (23mm x 100mm) Tweeter 2x80mm Woofer; 2 x (23mm x 100mm) Tweeter
Audio Power Output (10% THD)
31W RMS Total (13W + 2.5W) x 2 31W RMS Total (13W + 2.5W) x 2 31W RMS Total (13W + 2.5W) x 2 31W RMS Total (13W + 2.5W) x 2
Headphone Socket
3.5mm Stereo Jack 3.5mm Stereo Jack 3.5mm Stereo Jack 3.5mm Stereo Jack
Sound Modes
Music, Speech Music, Speech Music, Speech Music, Speech
Surround Sound Modes
Off, Simulated Surround, SRS TruSurround XT Off, Simulated Surround, SRS TruSurround XT Off, Simulated Surround, SRS TruSurround XT Off, Simulated Surround, SRS TruSurround XT
Connectivity
HDMI Inputs (v1.3/HDCP)
2 x Rear, 1 x Front 2 x Rear, 1 x Front 2 x Rear, 1 x Front 2 x Rear, 1 x Front
Component (YPbPr) Video/L & R Audio Inputs
2 x Rear 2 x Rear 2 x Rear 2 x Rear
S-Video (Y/C)/L&R Audio Inputs
1 x Rear, 1 x Front 1 x Rear, 1 x Front 1 x Rear, 1 x Front 1 x Rear, 1 x Front
Video (CVBS)/L&R Audio Inputs
3 x Rear, 1 x Front 3 x Rear, 1 x Front 3 x Rear, 1 x Front 3 x Rear, 1 x Front
PC Input (VGA 15 Pin D-Sub)/L&R Audio Input
1 x Rear 1 x Rear 1 x Rear 1 x Rear
Headphone out (3.5mm Stereo)
1 x Front 1 x Front 1 x Front 1 x Front
Monitor Out - Video (CVBS)/L&R Audio
1 x Rear 1 x Rear 1 x Rear 1 x Rear
Optical S/PDIF Digital Audio Out (DTV only)
1 x Rear 1 x Rear 1 x Rear 1 x Rear
Features
SDHC Memory Card Slot
Yes Yes Yes Yes
SDHC Memory Card Playback Formats
JPEG Photos/AVCHD JPEG Photos/AVCHD JPEG Photos JPEG Photos
Viera Link
Yes Yes Yes Yes
Power Off Timer Yes Yes Yes Yes
Remote Control Deluxe Deluxe Deluxe Deluxe
On Screen Display (OSD) Language(s) English English English English
User Definable A/V Input Labels Yes Yes Yes Yes
Weights & Measures
AC Power Input
220 - 240 VAC 50/60Hz 220 - 240 VAC 50/60Hz 220 - 240 VAC 50/60Hz 220 - 240 VAC 50/60Hz
Peak Power Consumption
779W 680W 640W 535W
Standby Power
0.4W 0.4W 0.5W 0.5W
Operating Temperature Range
0ºC - 35ºC 0ºC - 35ºC 0ºC - 35ºC 0ºC - 35ºC
Dimensions with Pedestal Stand (WxHxD)
1609x1060x419 (mm) 1454x970x418 (mm) 1266x850x369 (mm) 1077x736x330 (mm)
Dimensions without Pedestal Stand (WxHxD)
1609x998x142 (mm) 1454x918x144 (mm) 1266x802x138 (mm) 1077x689x138 (mm)
Weight with Pedestal Stand (WxHxD)
82kg 64kg 56kg 46kg
Weight without Pedestal Stand (WxHxD) 64kg 50.5kg 48kg 39kg
Wallmount fixing points (WxH) Thread Type 1075 x 470 (mm) - M8 660 x 320 (mm) - M8 660 x 320 (mm) - M8 660 x 320 (mm) - M8
Design, functions and specifications are subject to change without notice.
