15HF5443/10
Professional flat TV with Crystal Clear III
15" LCD HD Ready
Specifications Product highlights
Picture/Display
• Aspect ratio: 4:3
• Brightness: 450 cd/m²
• Contrast ratio (typical): 500:1
• Diagonal screen size: 15 inch / 38 cm
• Display screen type: LCD XGA Active Matrix TFT
• Picture enhancement: Progressive Scan, 2D
Combfilter, Active Control, Color Enhancement,
Sharpness Adjustment, Crystal Clear III
• Screen enhancement: Anti-Reflection coated
screen
• Viewing angle (h / v): 130 / 100 degree
• Panel resolution: 1024 x 768p
• Response time (typical): 16 ms
Supported Display Resolution
Sound
• Sound System: Nicam Stereo, Virtual Dolby
Surround
• Output power (RMS): 2 x 2W
• Sound Enhancement: Auto Volume Leveller
Convenience
• Ease of Installation: Fine Tuning, PLL Digital Tuning,
Program Name, Wireless Smart Loading, Advanced
Hotel Mode
• Ease of Use: FM Radio, Smart Picture Control,
Smart Sound Control, Side Control
• Remote control type: RC2886
• Teletext: 10 page Smart Text
• Remote Control: TV
• Screen Format Adjustments: 16:9 compress, 4:3,
4:3 expand
• Clock: Sleep Timer
• VESA Mount: 100 x 100 mm
• Comfort: Hotel Guest features
• Teletext enhancements: Fast text
• On-Screen Display languages: English, French,
German
Tuner/Reception/Transmission
• Tuner bands: Hyperband, S-Channel, UHF, VHF, FM
• TV system: PAL, PAL B/G, PAL D/K, PAL I, SECAM,
SECAM B/G, SECAM D/K, SECAM L/L'
• Video Playback: NTSC, PAL, SECAM
• Aerial Input: 75 ohm coaxial (IEC75)
• Tuner Display: PLL
• Number of Preset Channels: 125
Connectivity
• Number of Scarts: 1
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Other connections: Antenna IEC75, DVI-I, PC
Audio in
• Front / Side connections: S-video in, Headphone
out, Audio L/R in, CVBS in
• Connectivity Enhancements: SmartCard Xpress
box ready, HM-Link, RJ12 connector, RJ45
connector
Power
• Ambient temperature: 5 °C to 40 °C
• Power consumption: 42 W
• Mains power: AC 90-240V
Dimensions
• Box dimensions (W x H x D): 548 x 390 x 191 mm
• Color cabinet: Silver Frost & Black Deco Front
• Dimensions (with base) (W x H x D):
472
x 348 x 153 mm
• Set weight: 5 kg
• Set dimensions (W x H x D): 472 x 308 x 76.5 mm
• Weight incl. Packaging: 7.3 kg
Accessories
• Included Accessories: Power cord, Remote
Control, Table top stand, User Manual
• Optional accessories: Wireless SmartLoader
22AV1120, Set up Remote RC2573GR
Loudspeakers
• Built-in speakers: 2
•
• Computer formats
Resolution Refresh rate
720 x 400 70Hz
800 x 600 56, 60, 72, 75Hz
832 x 624 75Hz
1024 x 768 60, 70, 75Hz
640 x 480 60, 67, 72, 75Hz
• Video Formats
Resolution Refresh rate
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1280 x 720p 3Fh
1920 x 1080i 2Fh
Issue date 2007-12-14
Version: 6.0.7
12 NC: 8670 000 22832
EAN: 87 10895 89898 0
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Wireless SmartLoader
Provides the ability to copy easy and wireless all
programmming settings from one TV set into other TV sets
in less then a minute. The feature ensures uniformity
between TV sets and significantly reduces installation time
and costs.
Welcome message
A welcome greeting is displayed each time the TV set is
switched on.
Volume limitation
This feature predefines the volume range with which the
TV set is allowed to operate, preventing excessive volume
adjustments and avoiding disturbance of next door guests.
Front Controls Locking
Prevents unauthorised access to TV functions
Switch On Channel Programming
Perfect for in-house advertising or information channels as
it allows to show a predefined channel when the TV is
turned on.
Security Menu Access
Provides conditional access to installation and configuration
settings via a special code or master remote control
Built-in FM radio
The integrated FM radio offers guests additional comfort
without the extra investment in radio receivers.
Battery Low Detection
This feature informs of the need to replace the remote
control batteries preventing nuisance calls and
unneccessary replacement of batteries.
SmartCard Xpress Box
The optional SmartCard Xpress Box can be mounted at
the rear side of the TV set and allows third party decoders
and application cards to interface with the TV adding new
functionality to the TV. The TV can also be connected to
external decoders and set-top boxes of all major interactive
system providers, through the Serial Xpress Control
Interface (supporting UART and RS232 protocols) and the
SmartPlug Control interface.
Extra Power Supply (opt)
The (optional) Extra Power Supply ensures operation of the
Expansion Slot, the Clock Display and Wake-up Alarm
when the TV set is switched off.
Upgradable software
The upgradable software architecture ensures that the TV
is future proof and compatible with new technologies and
developments, securing your investment.
Crystal Clear III
Crystal Clear III combines a whole range of enhancements
to provide a better picture. They include a 2D Comb filter,
Dynamic contrast, Blue stretch and Green enhancement so
that you always get the most natural looking colors.
2D Combfilter
The 2D comb filter separates chrominance (color) from
luminance (brightness) information in the video signal for
independent processing to improve picture resolution and
minimize distortion.
