15LCD35
15LCD35
15" LCD FlatTV
Liquid Crystal (Display) Television works by trapping a liq-
uid crystal solution between two sheets of polarized glass.When
an electric voltage is put on the liquid crystals, they align so light
cannot pass trough.Each crystal then either blocks or allows light
to pass through it based on the broadcast information.For clear,
crisp color that rivals traditional CRT displays, a thin film transis-
tor,known as a TFT is employed.
LCD allows screens to be thinner, and televisions lighter and more
energy efficient than ever before.
75
DC 12V
ANT IN S-VIDEO
IN
PC INPUT
Y VIDEO
Pb
COMPONENT INPUT (480i)
Pr
L
AV
RAUDIO
Rear connectors
1
2
9
3
6
5
7
4
8
0
CC
MENU
OK
SLEEPEXT
CH
RC282605
©2002 Philips Consumer Electronics Co.
A Division of Philips Electronics North
America Corp.
Printed in USA
Specifications subject to change without notice.
Technical specifications
Screen / Picture
• Visible screen size :15.1"
• Picture Aspect Ratio 4:3
• LCD technology :Thin Film Transistor - TFT
• # pixels :1024 x 768
• Response time LCD :25ms (typical)
• Light output :400cd/m
2
• Contrast Ratio :300:1
• Viewing angles :140h / 120v
• Anti glare coating
• Progressive Scan
• De-interlacer
• Digital Comb filter (4H)
• Contrast / Brightness control
Sound
• Sound system :BTSC / SAP Stereo
• Output :2x1W RMS
• Speakers :2x1 full range - front firing
• Graphic Equalizer
•AVL
Operation
• EasyTune™
• Multi-language menu / OSD (Eng,Fre,Spa,Port)
• Sleeptimer up to 240 minutes.
• AutoLock™ to protect young kids from objec-
tionable programming with V-chip technology
• Closed Captioning
• Glow Remote Control
Reception
• Tuning system:PLL Digital Tuning
• Color transmission systems
Off-air:NTSC - M
NTSC video playback
• Channel selections :125 channels
• Aerial input:75 Ohm (F-threaded)
Remote Control
• RC282605
Connections
• PC-input
-D-sub 15pin,up to XGA 1024x768 / 85Hz
• Audio / Video
-Component video in
YUV-in / YPbPr (cinch) input + audio L-R
-Video CVBS in,audio L-R in(cinch)
-S-Video in (Y/C)
-headphone jack 3.5mm
• DC input
-12V / 3.5 A
• Antenna
- Input 75Ohm F-pin
Miscellaneous
• Ambient temperature :+0/+40°C
• Mains : AC 100-240V,50/60Hz
• Power consumption:50W (normal operation) ;
Stand by :<3W
• Weight :11.1 lbs (incl.‘arch’;excl.packaging)
• Dimensions (WxHxD):
product :17.4x12.4x2.0 in.(excl.‘arch’)
carton :20.9x17.7x9.9 in.
UPC : 0 37849 92614 7
15LCD35
EasyTune and AutoLock are trademarks of Philips
Consumer Electronics Company.
Internet address
http://www.philips.com
