THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND
FOLLOWED DURING BOTH INSTALLATION AND OPERATION.
WARNING: Raritan Engineering Company, Inc. recommends that a qualified person or electrician install this
product. Equipment damage, injury to personnel or death could result from improper installa-
tion. Raritan Engineering Company, Inc. accepts no responsibility or liability for damage to
equipment, or injury or death to personnel that may result from improper installation or
operation of this product.
WARNING: RISK OF SHOCK OR FIRE -
If the pump is operated in an area containing flammable vapors,
the wire leads must be joined by insulated mechanical locking connectors. Loose or inadequate
wire connections can spark, resulting in an explosion resulting in property damage, injury, or
death. Always use recommended fuse/circuit breaker and wire size.
Motors in this product are “Ignition Protected”. They are not however, explosion-proof as
defined in 46CFR 110.15-65(e), Subchapter J-Electrical Engineering.
WARNING: RISK OF FLOODING-Always shut off seacock(s) before leaving the boat unattended.
Whenever possible hose connections should be secured using two stainless steel hose clamps.
Integrity of clamps, hoses and fittings should be checked periodically.
Model 21P* Macerator Pump
Installation, Operation & Repair Manual
Raritan’s macerator pump is designed to empty marine and RV holding tanks of normal waste. It is
also an excellent choice for emptying fish boxes of scales and residual waste. A flow rate of up to 13
gallons per minute conveniently empties any tank in minutes. The unique dual-cut blade design ensures
waste is ground up thoroughly. The pump is self-priming to a five foot lift when impeller is wet, four
foot lift when impeller is dry, but for optimum performance and life, it should be mounted as close to
the tank as possible. Marine pump out must be in proper discharge zones only. This macerator
will not handle hard objects, rags, or feminine napkins.
1-800-352-5630
www.raritaneng. com
