Controls and Functions
CX-47HD/CX-OPAL47/CX-65HD Installation/Operation Manual 7
PRE
L
IMINAR
Y
Crystal Series LCD Inputs
and Outputs
Figure 2-2 and Figure 2-2 show the locations of the Crystal Series LCD inputs and
outputs.
Figure 2-2. Model CX-47HD and CX-OPAL47 Inputs and Outputs
SOURCE
RGB PC
Audio In
Speaker Out
HDMI 4HDMI 3HDMI 2HDMI 1
SPDIF Out
IR
In
MENU/EXIT
L R
–
+
COMPONENT 1 Video 1
Video 2
RS232
Video 2/
S-Video
COMPONENT 2
COMP 1 Audio
COMP 2 Audio Video 2 Audio
L R
L R
L R
L R
Video 1 Audio
2
8
10
12
1
7
11
4
3
5
6
9
