P L A S M A W A L L ™ F L A T P A N E L D I S P L A Y M O N I T O R S A N D P F P ™ C O N T R O L L E R S
PL-50HDX PLASMA SPECIFICATIONS:
Native Resolution: 1280 x 768
Screen Size: 50 in. (diagonal)
Screen Aspect Ratio: 16:9
Available Aspect Ratios: 4:3, Letterbox, 16:9 Anamorphic,
VirtualWide
Image Area (W x H): 43 1/4 in. (1099 mm) x
24 1/2 in. (622.30 mm)
DTV Compatibility: 480p, 720p, 1080i
Contrast Ratio: 1000:1
Data/Graphics Capability: 640 x 400 to 1600 x 1200
Inputs: (1) RGB/Component, (1) RGB 15 pin,
(1) DVI-Digital
Power Requirements: 100-120 VAC, 50/60 Hz
Power Consumption: 380W
Operating Environment: 32°– 104º F (0º– 40ºC), 20 – 80%
Humidity (non-condensing)
Dimensions: Width: 49 1/4 in. (1251 mm)
Depth: 4 3/8 in. (111.13 mm)
Height: 30 1/8 in. (765.20 mm)
Weight: 96 lbs. (44.0 kg)
Regulatory Approvals: FCC
Limited Warranty: (3) Three years parts and labor (not
including plasma glass panel) from
the date of delivery to the end user.
(1) One year parts and labor on the
plasma glass panel from the date
of delivery to the end user.
T
he spectacular PL-50HDX flat-
panel plasma monitor brings
outstanding picture quality to the
50-inch size category with true
high definition native resolution
of 1280 x 768 for no-compromise
viewing of any video source.
Black level performance and
shadow detail capability have been
enhanced with Active Gray Scale
Rendering to provide smoother
transitions from dark to light,
resulting in richly detailed textures
even in shadowy scenes.
The PL-50HDX is easily integrated
into custom installation systems.
Both RS-232C and IR control inter-
faces are incorporated for simple
automation. Its profile is less than
4 1/2 inches thin for wall-mounting
simplicity.
Multiple aspect ratio control includes
Runco’s VirtualWide for viewing 4:3
material in widescreen with no loss
of picture quality. The PL-50HDX is
fully HDTV ready and also includes a
480p digital DVI input.
The PL-50HDX is supplied with
Runco’s award winning PFP™ con-
troller, which provides Pixel for
Pixel™ resolution and state-of-the-
art ViVix™ video processing for the
finest, artifact-free image quality.
This controller even brings standard
NTSC sources to near high defini-
tion levels.
FEATURES:
• 1280 x 768 native resolution
• Multiple aspect ratios
• 160 degree horizontal/vertical viewing angle
• Accepts all DTV formats (via outboard decoder), including
1080i, 720p, 480p
• Full control options, including RS-232C and IR
• Includes the Runco Vivix PFP Controller for extremely
high-quality NTSC Video processing
• Only 4 1/2 inches thin
Tablestand or wall mount available separately
12/03
Inputs: (1) Composite, (1) S-Video,
(1) Component, (1) Pass-through
Video Standards: NTSC, PAL
Bandwidth: Composite, S-Video and
Component inputs: 5.5 MHz,
Pass-through: 100 MHz
Power Requirements: 100 – 240 VAC, 50/60 Hz
Power Consumption: 15W
Control Options: RS-232, IR, Front Panel
Operating Environment: 41°– 95°F (5°-35° C), 0 – 90%
Humidity (non-condensing)
Dimensions: Width: 17 1/2 in. (443.23 mm)
Depth: 16 in. (406.40 mm)
Height: 3 1/2 in. (88.90 mm)
Weight: 16 lbs. (7.26 kg)
Regulatory Approvals: Complies with UL, FCC Class ‘B’,
CE, C-tick
Limited Warranty: (2) Two years parts and labor
from the date of delivery to the
end user.
PFP CONTROLLER SPECIFICATIONS (Included with the PL-50HDX):
Runco International
®
2900 Faber Street, Union City, CA 94587
Tel: 510-324-7777 • Fax: 510-324-9300
www.runco.com
Call factory for more specific information on export specifications. Specifications are subject to change without notice.
