Runco PlasmaWall Owner’s Operating Manual ix
1List of Figures
PRE
L
IMINAR
Y
2-1. PlasmaWall Controls and Indicators .............................................................................5
2-2. PlasmaWall Connectors ...............................................................................................6
2-3. DHD Controller Front Panel ..........................................................................................8
2-4. DHD Controller Rear Panel.........................................................................................10
2-5. DHD Controller Remote Control .................................................................................12
3-1. Available Range of the Remote Control ......................................................................15
3-2. Ventilation Requirements for Enclosure Mounting .......................................................19
3-3. Connecting the PlasmaWall to the DHD Controller .....................................................20
3-4. RS-232 Connection from the DHD Controller to the PlasmaWall ................................21
3-5. DVI Source Connections ............................................................................................22
3-6. Digital (DTV) RGB Connections...................................................................................23
3-7. Analog RGB Connections...........................................................................................24
3-8. Composite, S-Video and Component Video Connections...........................................25
3-9. RS-232 Control System Connection...........................................................................26
3-10. Connecting 12-Volt Trigger Outputs .........................................................................26
3-11. Installing the Cable Clamps ......................................................................................27
4-1. Attaching the Ferrite Cores to the Power Cable ..........................................................29
4-2. DHD Controller OSD Menu Structure for PlasmaWall..................................................32
4-3. Typical PLUGE Pattern for Adjusting Brightness .........................................................35
4-4. Typical Gray Bar Pattern for Adjusting Contrast..........................................................36
4-5. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................37
4-6. Typical Test Pattern for Adjusting Sharpness..............................................................38
7-1. PlasmaWall Model PL-50XA Dimensions ....................................................................53
7-2. PlasmaWall Model PL-61DHD Dimensions.................................................................54
