Controls and Functions
Vidikron VL-40 and VL-46 Owner’s Operating Manual 7
PRE
L
IMINAR
Y
8. HDMI1/Computer Input (Digital)
9. HDMI2/Computer Input (Digital)
Two, HDCP-compliant digital video inputs for connecting a DVD player, personal
computer or HD tuner with a DVI or HDMI output.
10. PC Audio Input
Connect the audio output from a personal computer here.
11. INPUT3 Component Video (RCA connectors)
Standard-definition (480i/576i) or high-definition (720p/1080i), YPrPb component input.
This is the input for component video from sources such as DVD players.
12. INPUT3 Composite Video Input
13. INPUT3 Audio Input
Connect the audio output from your Input 3 source here.
14. INPUT4 Component Video (RCA connectors)
Standard-definition (480i/576i) or high-definition (720p/1080i), YPrPb component input.
This is the input for component video from sources such as DVD players.
15. INPUT4 Composite Video Input
16. INPUT4 Audio Input
Connect the audio output from your Input 4 source here.
17. INPUT1 Composite Video Input
18. INPUT1 Audio Input
Connect the audio output from your Input 1 source here.
19. INPUT1 S-Video Input
20. AV-OUT (Composite Video)
21. AV-OUT (Audio)
22. DIGITAL AUDIO OUT (S/PDIF – Coaxial)
23. DIGITAL AUDIO OUT (TosLink – Optical)
Connect either #22 or #23 to the digital audio input of an A/V amplifier with a Dolby
Digital
®
decoder.
24. AIR (Antenna) Input
75-ohm coaxial input for connecting a TV antenna to the digital TV input.
25. CABLE Input
75-ohm coaxial input for connecting a CATV system to the digital TV input.
26. RS-232 CONTROL PORT
A female, 9-pin D-sub connector for interfacing with a PC or home theater
automation/control system.
27. SPEAKER OUTPUT (RIGHT)
28. SPEAKER OUTPUT (LEFT)
For connection of the right (27) left (28) speakers. Connect a speaker with an impedance
of 4 ohms.
For best results, do not run your DVD player in progressive mode.
Tip
