Samsung PN60E530A3FXZA Flat Panel Television User Manual


  Open as PDF
of 2

Kensington Lock
The✎Kensington✎Lock✎is✎not✎supplied✎by✎Samsung.✎It✎is✎a✎device✎
used✎to✎physically✎fix✎the✎system✎when✎using✎it✎in✎a✎public✎place.✎
Refer✎to✎the✎manual✎provided✎with✎the✎Kensington✎Lock✎for✎additional✎
information✎on✎proper✎use.
✎✎ Please✎find✎a✎“

”✎icon✎o n✎the✎rear✎of✎the✎TV.✎The✎Kensington✎
slot✎is✎beside✎the✎“

”✎icon.
✎✎ The✎position✎and✎color✎may✎differ✎dependi ng✎on✎the✎m odel.
To lock the product, follow these steps:
1. Wrap✎the✎Kensington✎lock✎cable✎around✎a✎large,✎stationary✎object✎
such✎as✎desk✎or✎chair.
2. Slide✎the✎end✎of✎the✎cable✎with✎the✎lock✎attached✎through✎the✎
looped✎end✎of✎the✎Kensington✎lock✎cable.
3. Insert✎the✎locking✎device✎into✎the✎Kensington✎slot✎on✎the✎product.
4. Lock✎the✎lock.
✎✎ These✎are✎general✎instructions.✎For✎exact✎instructions,✎see✎the✎
User✎manual✎supplied✎with✎the✎locking✎device.
✎✎ The✎locking✎device✎has✎to✎be✎purchased✎separately.
✎✎ The✎location✎of✎the✎Kensington✎slot✎may✎be✎different✎depending✎
on✎the✎TV✎model.
Display Modes (HDMI/DVI Input)
Optimal✎resolution✎is✎1920✎x✎1080@60Hz.✎
Mode Resolution
Horizontal✎
Frequency✎(KHz)
Vertical✎Frequency✎
(Hz)
Pixel✎Clock✎
Frequency✎(MHz)
Sync✎Polarity✎
(H✎/✎V)
IBM
✎640✎x✎350 31.469✎ 70.086✎ 25.175✎ +/-
✎720✎x✎400 31.469✎ 70.087✎ 28.322✎ -/+
MAC
✎640✎x✎480 35.000✎ 66.667✎ 30.240✎ -/-
832✎x✎624 49.726✎ 74.551✎ 57.284✎ -/-
1152✎x✎870 68.681✎ 75.062✎ 100.000✎ -/-
VESA✎DMT
✎640✎x✎480 31.469✎ 59.940✎ 25.175✎ -/-
✎640✎x✎480 37.861✎ 72.809✎ 31.500✎ -/-
✎640✎x✎480 37.500✎ 75.000✎ 31.500✎ -/-
✎800✎x✎600 37.879✎ 60.317✎ 40.000✎ +/+
800✎x✎600 48.077✎ 72.188✎ 50.000✎ +/+
800✎x✎600 46.875✎ 75.000✎ 49.500✎ +/+
1024✎x✎768 48.363✎ 60.004✎ 65.000✎ -/-
1024✎x✎768 56.476✎ 70.069✎ 75.000✎ -/-
1024✎x✎768 60.023✎ 75.029✎ 78.750✎ +/+
1152✎x✎864 67.500✎ 75.000✎ 108.000✎ +/+
✎1280✎x✎720✎ 45.000✎ 60.000✎ 74.250✎ +/+
1280✎x✎800 49.702✎ 59.810✎ 83.500✎ -/+✎
1280✎x✎1024 63.981✎ 60.020✎ 108.000✎ +/+
1280✎x✎1024 79.976✎ 75.025✎ 135.000✎ +/+
1366✎x✎768 47.712✎ 59.790✎ 85.500✎ +/+
1440✎x✎900 55.935✎ 59.887✎ 106.500✎ -/+✎
1600✎x✎900RB 60.000✎ 60.000✎ 108.000✎ +/+
1680✎x✎1050✎ 65.290✎ 59.954✎ 146.250✎ -/+✎✎
1920✎x✎1080 67.500✎ 60.000✎ 148.500✎ +/+
2. Press✎the✎▲✎or✎▼ button✎to✎select✎Media Play (USB),✎and✎then✎
press✎the✎ENTER

✎button.
3. Press✎the✎◄✎or✎►✎button✎to✎select✎an✎icon✎(Videos, Music,
Photos, Settings),✎and✎then✎press✎the✎ENTER

✎button.
✎✎ Media✎Play✎might✎not✎work✎pr operly✎with✎unlicensed✎
multimedia✎files.
✎✎ Need-to-Kn ow✎List✎before✎usin g✎ Media Play (USB)
✎x The✎file✎system✎supports✎FAT16,✎FAT32✎an d✎NT FS.
✎x Certain✎types✎of✎USB✎Digital✎camera✎and✎audio✎devices✎may✎not✎
be✎compatib le✎with✎t his✎TV.
✎x Media Play only✎supports✎USB✎Mass✎Storage✎Class✎(M SC)✎
devices.✎MSC✎is✎a✎Mass✎Sto rage✎Class✎Bulk-Only✎Transport✎
device.✎Examples✎of✎MSC✎a re✎Thumb✎drives✎and✎Flash✎Card✎
Readers.✎Devices✎should✎be✎connected✎directly✎to✎the✎TV’s✎USB✎
port.✎USB✎HDD✎is✎not✎supporte d.✎
✎x Before✎connecting✎your✎device✎to✎the✎TV,✎please✎back✎up✎your✎
files✎to✎prevent✎them✎from✎damage✎or✎loss✎of✎data.✎SAMSUNG✎is✎
not✎r espons ible✎for✎any✎data✎file✎damage✎or✎data✎loss.
✎x A✎USB✎device✎that✎requires✎high✎power✎(more✎than✎0.5A)✎may✎not✎
be✎supported.
✎x Do✎not✎disconnect✎the✎USB✎device✎while✎it✎is✎loading.
✎x The✎higher✎the✎resolution✎of✎the✎image,✎the✎longer✎it✎takes✎to✎
display✎on✎the✎screen.
✎x The✎maximum✎supported✎JPEG✎resolution✎is✎15360✎x✎8640✎pixels.
✎x If✎a✎file✎is✎corrupted✎or✎the✎TV✎does✎not✎support✎the✎file✎type,✎the✎
“Not✎Supported✎File✎Format”✎message✎appears.
✎x The✎TV✎cannot✎play✎MP3✎files✎with✎DRM✎that✎have✎been✎
downloaded✎from✎a✎for-pay✎site.✎Digital✎Rights✎Management✎
(DRM)✎is✎a✎technology✎that✎supports✎the✎creation,✎distribution,✎
and✎management✎of✎digital✎content✎in✎an✎integrated✎and✎
comprehensive✎way,✎including✎protecting✎the✎rights✎and✎interests✎
of✎content✎providers,✎pr eventing✎illegal✎copying✎of✎contents,✎and✎
managing✎billing✎and✎settlements.
✎x PTP✎devices✎are✎not✎supported.
✎x If✎an✎over-power✎warning✎message✎is✎displayed✎while✎you✎are✎
connecting✎or✎using✎a✎USB✎device,✎the✎device✎may✎not✎be✎
recognized✎or✎may✎malfunction.
✎x If✎the✎TV✎has✎no✎input✎during✎the✎time✎period✎set✎in✎Auto
Protection Time,✎the✎Screensaver✎will✎run.
✎x The✎power-saving✎mode✎of✎some✎external✎hard✎disk✎drives✎may✎be✎
released✎automatically✎when✎your✎connect✎them✎to✎the✎TV.
✎x If✎you✎use✎a✎USB✎extension✎cable,✎the✎TV✎may✎not✎recognize✎the✎
USB✎device✎or✎may✎not✎be✎able✎to✎read✎the✎files✎on✎the✎device.
✎x If✎a✎USB✎device✎connected✎to✎the✎TV✎is✎not✎recognized,✎the✎list✎of✎
files✎on✎the✎device✎is✎cor rupted,✎or✎a✎file✎in✎the✎list✎is✎not✎played,✎
connect✎the✎USB✎device✎to✎a✎PC,✎format✎the✎device,✎and✎check✎
the✎connection.
✎x If✎a✎file✎you✎deleted✎from✎the✎PC✎is✎still✎found✎when✎you✎run✎Media
Play,✎use✎the✎“Empty✎the✎Recycle✎Bin”✎function✎on✎the✎PC✎to✎
permanently✎delete✎the✎file.
✎x Photos✎only✎supports✎the✎sequential✎jpeg✎format.
✎x The✎Videos✎option✎does✎not✎support✎the✎scene✎search✎and✎
thumbnail✎functions.✎
✎x If✎the✎number✎of✎files✎and✎folders✎saved✎on✎a✎USB✎storage✎device✎is✎
over✎approximately✎4000,✎the✎files✎and✎folders✎may✎not✎appear✎and✎
some✎folders✎may✎not✎open.
✎x The✎maximum✎displayed✎number✎of✎files,✎including✎sub✎folders,✎in✎
one✎folder✎of✎USB✎storage✎device✎is✎2000.
✎x The✎media✎may✎not✎be✎playing✎smoothly✎when✎using✎the✎device✎
lower✎than✎USB✎2.0.✎
Videos
SUM
00:04:03 / 00:07:38
►
1/1
Movie 01.avi

Pause

Jump

Tools

Return
1. In✎the✎Media Play✎menu,✎press✎the✎◄✎or✎►✎button✎to✎select✎
Videos,✎and✎then✎press✎the✎ENTER

✎button.
2. Press✎the✎◄/►/▲/▼✎buttons✎to✎select✎a✎video✎in✎the✎file✎list.
3. Press✎the✎ENTER

✎button✎or✎

✎(Play)✎button.
✎- The✎file✎name✎is✎displayed✎on✎the✎top✎of✎the✎screen✎with✎the✎
playing✎time.
✎- If✎video✎time✎information✎is✎unknown,✎playing✎time✎and✎the✎
progress✎bar✎are✎not✎displayed.
✎- During✎video✎playba ck,✎you✎can✎search✎usi ng✎the✎
◄
✎and✎
►
✎buttons.
✎✎ In✎this✎m ode,✎you✎can✎play✎movie✎cl ips✎contained✎in✎a✎game,✎
but✎you✎cannot✎play✎t he✎game✎itself.
✎y Supported✎Subtitle✎Formats
✎- External
Name File extension
MPEG-4✎timed✎text .ttxt
SAMI .smi
SubRip .srt
SubViewer .sub
Micro✎DVD .sub✎or✎.txt
SubStation✎Alpha .ssa
Advanced✎SubStation✎Alpha .ass
✎- Internal
Name Container Format
Xsub AVI Picture✎Format
SubStation✎Alpha MKV Text✎Format
Advanced✎SubStation✎Alpha MKV Text✎Format
SubRip MKV Text✎Format
MPEG-4✎Timed✎text MP4 Text✎Format
✎y Supported✎Video✎Formats
File✎
Extension
Container Video✎Codec Resolution
Frame✎
rate(fps)
Bit✎
rate(Mbps)
Audio✎
Codec
*.mp4 MP4
DivX✎
3.11/4.x/5.1✎
/6.0
1920x1080 6~30 30Mbps
MP3✎/✎
ADPCM✎/✎
AAC
H264 1920x1080 6~30 30Mbps
AVC 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
*.avi✎
*.mkv
AVI,✎
MKV
DivX✎
3.11/4.x/5.1✎
/6.0
1920x1080 6~30 30Mbps
MP3✎/✎
AC3✎/✎
LPCM✎/✎
ADPCM✎
/✎DTS✎
Core
MPEG4✎SP✎
/✎ASP
1920x1080 6~30 30Mbps
H264 1920x1080 6~30 30Mbps
MJPEG 640x480 6~30 10Mbps
*.asf✎
*.wmv
ASF
DivX✎3.11✎
/✎4.x✎/5.1✎
/✎6.0
1920x1080 6~30 30Mbps
MP3✎/✎
AC3✎/✎
LPCM✎/
ADPCM✎
/✎WMA✎
/✎WMA✎
Pro
MPEG4✎SP✎
/✎ASP
1920x1080 6~30 30Mbps
H.264 1920x1080 6~30 30Mbps
*.ts✎
*.trp✎
*.tp
*.m2ts
TS
MPEG2 1920x1080 6~30 30Mbps
AC3✎/✎
AAC✎/✎
MP3✎/✎
DD+✎/✎
✎HE-AAC
H.✎264✎BP✎
✎/✎MP✎/✎HP
1920x1080 6~30 30Mbps
*.dat✎
*.mpg✎
*.mpeg✎
*.vob
PS
MPEG1 1920x1080 24/25/30 30Mbps
AC3✎/✎
MPEG✎/✎
LPCM✎/✎
AAC
MPEG2 1920x1080 24/25/30 30Mbps
H.✎264✎BP✎
✎/✎MP✎/✎HP
1920x1080 6~30 30Mbps
*.3gp 3GPP
MPEG4✎SP✎
/✎ASP
1920x1080 6~30 30Mbps
MP3
H.264 1920x1080 6~30 30Mbps
File✎
Extension
Container Video✎Codec Resolution
Frame✎
rate(fps)
Bit✎
rate(Mbps)
Audio✎
Codec
*.flv✎
*.swf
flash✎
formats
H.264 1920x1080 6~30 30Mbps
MP3
Sorenson✎✎
H.263
1920x1080 6~30 30Mbps
Other Restrictions
✎y Video✎content✎will✎not✎play,✎or✎not✎play✎correctly,✎if✎there✎is✎an✎error✎
in✎the✎content✎or✎the✎container.
✎y Sound✎or✎video✎may✎not✎work✎if✎the✎contents✎have✎a✎standard✎
bit✎rate/✎frame✎rate✎above✎the✎compatible✎Frame/sec✎listed✎in✎the✎
Supported✎Video✎Formats✎table.
✎y If✎the✎Index✎Table✎erroneous,✎the✎Seek✎(Jump)✎function✎is✎not✎
supported.
✎y The✎menu✎may✎take✎longer✎to✎appear✎if✎the✎video’s✎bit✎rate✎
exceeds✎10Mbps.
✎y Video✎content✎can✎not✎be✎played✎if✎there✎are✎many✎contents✎in✎
one✎file.
Video Decoder
Supports✎up✎to✎H.264,✎Level✎4.1
H.264✎FMO✎/✎ASO✎/✎RS,✎VC1✎SP✎/✎MP✎/✎AP✎L4✎and✎AVCHD✎are✎
not✎supported.
MPEG4✎SP,✎ASP✎:
–✎Below✎1280✎x✎720:✎60✎frame✎max
–✎Above✎1280✎x✎720:✎30✎frame✎max
H.263✎is✎not✎supported.
GMC✎is✎not✎support.
Audio Decoder
Supports✎up✎to✎WMA7,✎8,✎9✎STD,✎9✎PRO,✎10✎PRO
WMA✎9✎PRO✎and✎WMA✎10✎PRO✎support✎5.1✎channel.✎(LBR✎
mode✎of✎WMA✎Pro✎is✎not✎supported)
WMA✎Lossless✎is✎not✎supported.
Music
3/15
I Love you
Jhon
Music 1
No Singer
Music 2
No Singer
Music 3
No Singer
Music 4
No Singer
Music 5
No Singer
I Love You
Jhon
1st Album
Pop
2010
4.2MB
01:10 / 04:02
SUM

Pause

Jump

Tools

Return
Playlist
1. In✎the✎Media Play✎menu,✎press✎the✎◄✎or✎►✎button✎to✎select✎
Music,✎and✎then✎press✎the✎ENTER

✎button.
2. Press✎the✎◄/►/▲/▼✎buttons✎to✎select✎the✎desired✎Music✎in✎the✎
file✎list.
3. Press✎the✎ENTER

✎button✎or✎✎(Play)✎button.
✎✎ During✎m usic✎playback,✎you✎can✎search✎using✎the✎◄✎and✎
►✎button.
✎✎

(REW)✎and✎

✎(FF)✎buttons✎do✎not✎function✎during✎
play.
✎✎ Media✎Play✎only✎displays✎files✎with✎MP3✎and✎PCM✎file✎
extension.✎Other✎file✎extensi ons✎are✎not✎displayed,✎even✎if✎they✎
are✎saved✎on✎the✎sam e✎USB✎device .
✎✎ If✎the✎sound✎is✎abnormal✎when✎playing✎MP3✎files,✎adjus t✎the✎
Equalizer✎in✎the✎Sound✎menu.✎(An✎over-modula ted✎MP3✎file✎
may✎cause✎a✎sound✎problem .)
Photos
Image1024.jpg 1024x768 2010/2/1 3/15
SUM

Pause

Previous/Next

Tools

Return
Normal
1. In✎the✎Media Play✎menu,✎press✎the✎◄✎or✎►✎button✎to✎select✎
Photos,✎then✎press✎the✎ENTER

✎button.
2. Press✎the✎◄/►/▲/▼✎buttons✎to✎select✎a✎photo✎in✎the✎file✎list.
3. Press✎the✎ENTER

✎button✎or✎

✎(Play)✎button.
✎✎ NOTE
✎x While✎a✎photo✎list✎is✎displayed,✎press✎the✎

✎(Play)✎/✎ENTER

✎
button✎on✎the✎remote✎control✎to✎start✎a✎slide✎show.
✎x All✎files✎in✎the✎file✎list✎section✎will✎be✎displayed✎in✎the✎slide✎show.
✎x During✎the✎slide✎show,✎files✎are✎displaye d✎in✎order.
✎x During✎the✎slide✎show,✎you✎can✎adjust✎the✎slide✎show✎speed✎
using✎(π)✎(REW)✎or✎(µ)✎(FF)✎button.
✎x You✎can✎move✎to✎other✎file s✎using✎◄✎or✎►✎button.
✎✎ Media✎Play✎can✎play✎Mu sic✎files✎automatically✎during✎a✎Slide✎
Show✎if✎Background Music✎is✎set✎to✎On.
✎✎ You✎cannot✎c hange✎the✎Mode in Background Music✎until✎the✎
Background✎Music✎file✎has✎finished✎loading.
✎y Supported✎Photo✎Formats
Image Photo Resolution
JPEG
Base-line 15360✎x✎8704
Progressive 1024✎x✎768
Other Restrictions
✎y CMYK,✎YCCK✎Color✎space✎JPEG✎are✎not✎supported.
Playing Multiple Files
■
Playing selected video/music/photo les
1. On✎the✎File✎List✎screen,✎highlight✎a✎file,✎and✎then✎press✎the✎Yellow✎
button✎on✎your✎remote.
2. Repeat✎Step✎1✎to✎select✎multiple✎files.
✎✎ NOTE
✎x A✎

✎mark✎appear s✎to✎the✎left✎of✎the✎selected✎files.
✎x To✎canc el✎a✎s election,✎press✎the✎Yellow✎b utton✎again.✎
✎x To✎deselect✎all✎selected✎file s,✎press✎the✎TOOLS✎b utton,✎select✎
Deselect All, and✎then the✎ENTER

✎button.
3. Press✎the✎TOOLS✎button,✎select✎Play Selected Contents,✎and✎
then✎press✎the✎ENTER

✎button.
■
Playing a video/music/photo folder
1. With✎the✎folders✎on✎your✎USB✎device✎displayed,✎use✎the✎
◄/►/▲/▼✎buttons✎to✎highlight✎a✎folder.
2. Press✎the✎TOOLS✎button,✎select✎Play Folder,✎and✎then✎press✎the✎
ENTER

✎button.
Media Play - Additional Functions
■
Videos/Music/Photos Play Option menus
When✎playing✎a✎file,✎press✎the✎TOOLS✎button.
Category Operation Videos Music Photos
Title
You✎can✎select✎another✎video✎file✎
to✎play✎directly.

Repeat✎Mode
You✎can✎play✎movie✎and✎music✎
files✎repeatedly.
 
Picture✎Size✎
You✎can✎adjust✎the✎picture✎size✎to✎
your✎preference.

Picture✎Mode You✎can✎adjust✎the✎picture✎setting.✎
 
Sound✎Mode You✎can✎adjust✎the✎sound✎setting.
  
Subtitle✎Setting
You✎can✎play✎the✎video✎with✎
Subtitles.✎This✎function✎only✎works✎
if✎the✎subtitles✎have✎the✎same✎file✎
name✎as✎the✎video.

Audio✎Format
You✎can✎select✎the✎digital✎audio✎
output✎format.

Audio✎
Language
You✎can✎change✎the✎audio✎
language✎if✎the✎video✎has✎more✎
than✎one✎language.

Stop✎Slide✎
Show✎/✎
Start✎Slide✎
Show
You✎can✎start✎or✎stop✎a✎Slide✎
Show.

Slide✎Show✎
Speed
You✎can✎select✎the✎slide✎show✎
speed✎during✎the✎slide✎show.

Background✎
Music
You✎can✎set✎and✎select✎
background✎music✎when✎
watching✎a✎Slide✎Show.

Zoom
You✎can✎zoom✎into✎images✎in✎full✎
screen✎mode.

Rotate
You✎can✎rotate✎images✎in✎full✎
screen✎mode.

Information
You✎can✎see✎detailed✎information✎
about✎the✎played✎file.
  
Settings
Using the Setup Menu
■
DivX® Video On Demand :✎Shows✎the✎registration✎code✎
authorized✎for✎the✎TV.✎If✎you✎connect✎to✎the✎DivX✎web✎site✎and✎
register✎with✎the✎10-digit✎registration✎code,✎you✎can✎download✎
the✎VOD✎activation✎file.✎Once✎you✎play✎it✎using✎Media✎Play,✎the✎
registration✎is✎completed.
✎✎ For✎more✎information✎on✎DivX®✎VOD,✎visit✎“http://vod.divx.
com”.
■
Information:✎Select✎to✎view✎information✎about✎the✎connected✎
USB✎device.
Other Information
Installing the Wall Mount Kit
The✎wall✎mount✎kit✎(sold✎separately)✎allows✎you✎to✎mount✎the✎TV✎on✎
the✎wall.
For✎detailed✎information✎about✎installing✎the✎wall✎mount,✎see✎
the✎instructions✎provided✎with✎the✎wall✎mount✎items.✎Contact✎a✎
technician✎for✎assistance✎when✎installing✎the✎wall✎mount✎bracket.✎
Samsung✎Electronics✎is✎not✎responsible✎for✎any✎damage✎to✎the✎
product✎or✎injury✎to✎yourself✎or✎others✎if✎you✎elect✎to✎install✎the✎wall✎
mount✎on✎your✎own.
Wall Mount Kit Specications (VESA)
✎✎ The✎wall✎mount✎kit✎is✎not✎supplied,✎but✎sold✎separately.
Install✎your✎wall✎mount✎on✎a✎solid✎wall✎perpendicular✎to✎the✎floor.✎
When✎attaching✎to✎other✎building✎materials,✎please✎contact✎your✎
nearest✎dealer.✎If✎you✎install✎the✎TV✎on✎a✎ceiling✎or✎slanted✎wall,✎it✎
may✎fall✎and✎result✎in✎severe✎personal✎injury.
✎✎ NOTE
✎x Standard✎dimensions✎for✎wall✎mount✎kits✎are✎shown✎in✎the✎table✎
below.
✎x When✎purchasing✎our✎wall✎mount✎kit,✎a✎detailed✎installation✎
manual✎and✎all✎parts✎necessary✎for✎asse mbly✎are✎provided.
✎x Do✎not✎use✎screws✎that✎do✎not✎comply✎with✎the✎VESA✎standard✎
screw✎specif ic ations.
✎x Do✎not✎use✎screws✎that✎are✎longer✎than✎the✎standard✎dimension✎
or✎do✎not✎comply✎with✎the✎VESA✎standard✎screw✎specifications.✎
Screws✎that✎are✎too✎long✎may✎cause✎damage✎to✎the✎inside✎of✎the✎
TV✎set.
✎x For✎wall✎mounts✎tha t✎do✎not✎comply✎with✎the✎VESA✎s tandard✎
screw✎specif ic ations,✎the✎length✎of✎the✎screws✎may✎differ✎
depending✎on✎the✎wall✎mount✎specifications.
✎x Do✎not✎fasten✎the✎screws✎too✎firml y.✎This✎may✎damage✎the✎
product✎or✎cause✎the✎product✎to✎fall,✎leading✎to✎personal✎injury.✎
Samsun g✎is✎not✎liable✎for✎thes e✎kinds✎of✎accidents .
✎x Samsun g✎is✎not✎liable✎for✎product✎damage✎or✎personal✎injury✎
when✎a✎non-VESA✎or✎non-specified✎wall✎moun t✎is✎used✎or✎the✎
cons umer✎fails✎to✎follow✎the✎pro duct✎installation✎instructions.
✎x Do✎not✎mount✎the✎TV✎at✎more✎than✎a✎15✎degr ee✎tilt.
✎x Alway s✎have✎two✎people✎mount✎the✎TV✎on✎a✎wall .
Product✎
Family
TV✎size✎in✎
inches
VESA✎screw✎hole✎
specs✎(A✎*✎B)✎in✎
millimeters
Standard✎
Screw
Quantity
PDP-TV
43~51 400✎X✎400
M8 4
60~64 600✎X✎400
Do✎not✎install✎your✎Wall✎Mount✎Kit✎
while✎your✎TV✎is✎turned✎on.✎It✎may✎
result✎in✎personal✎injury✎due✎to✎
electric✎shock.
Securing the TV to the Wall
Caution:✎Pulling,✎pushing,✎or✎climbing✎onto✎the✎TV✎may✎cause✎
the✎TV✎to✎fall.✎In✎particular,✎ensure✎that✎your✎children✎do✎not✎hang✎
over✎or✎destabilize✎the✎TV;✎doing✎so✎may✎cause✎the✎TV✎to✎tip✎over,✎
resulting✎in✎serious✎injuries✎or✎death.✎Follow✎all✎safety✎precautions✎
provided✎on✎the✎included✎Safety✎Flyer.✎For✎added✎stability,✎install✎
the✎anti-fall✎device✎for✎safety✎purposes,✎as✎follows.
To prevent the TV from falling
✎✎ Since✎the✎necessary✎brackets,✎screws,✎and✎string✎or✎cable✎are✎
not✎supplied,✎please✎purchase✎these✎separately.
1. Insert✎the✎screws✎into✎the✎wall✎brackets✎and✎firmly✎fasten✎them✎to✎
the✎wall.✎Make✎sure✎the✎screws✎are✎firmly✎fixed✎to✎the✎wall.
✎✎ We✎strongly✎rec ommend✎you✎dr ive✎the✎screws✎into✎a✎stud.
2. Using✎M8✎screws,✎insert✎the✎screws✎through✎the✎TV✎brackets,✎
and✎then✎fasten✎the✎screws✎to✎the✎top✎VESA✎screw✎holes✎on✎the✎
back✎of✎the✎TV.
3. Connect✎the✎brackets✎on✎the✎TV✎and✎the✎brackets✎on✎the✎wall✎
with✎a✎strong✎string✎or✎cable,✎and✎then✎tie✎the✎string✎or✎cable✎
tightly✎to✎the✎brackets.
✎✎ Verify✎all✎connecti ons✎are✎properly✎secured.✎Periodically✎check✎
the✎connect ions✎for✎any✎sign✎of✎fatigue✎or✎failure.✎If✎you✎have✎
any✎doubt✎about✎the✎se curity✎of✎your✎connections,✎contact✎a✎
professional✎installer.
✎✎ Install✎the✎TV✎close✎to✎the✎wal l✎so✎that✎it✎does✎not✎fall.
✎✎ Connect✎the✎string✎or✎cable✎so✎that✎the✎brackets✎o n✎the✎wall✎
are✎at✎the✎same✎height✎or✎lower✎than✎the✎brackets✎on✎the✎TV.✎
Untie✎the✎string✎or✎cable✎before✎mo ving✎the✎TV.
✎✎ To✎purca se✎a✎TV✎Holder✎kit,✎contact✎Samsung✎customer✎care.
Troubleshooting
If✎the✎TV✎seems✎to✎have✎a✎problem,✎first✎review✎this✎list✎of✎possible✎problems✎and✎solutions.✎If✎none✎of✎these✎troubleshooting✎tips✎apply,✎visit✎
samsung.com,✎then✎click✎on✎Support,✎or✎call✎Samsung✎customer✎service✎at✎1-800-SAMSUNG.
Problem Possible Solution
Flickering✎and✎Dimming If✎your✎Samsung✎Television✎is✎flickering✎or✎dimming✎sporadically,✎you✎may✎need✎to✎disable✎some✎of✎its✎energy✎efficient✎
features✎like✎the✎Eco✎Sensor✎or✎the✎Energy✎Saving✎feature.✎Follow✎the✎steps✎below✎with✎your✎remote✎to✎turn✎these✎
features✎off✎or✎on.
✎y Energy saving✎:✎Menu✎→✎Setup →✎Eco Solution → Energy Saving →Select Settings
✎y Eco Sensor : Menu → Setup → Eco Solution → Eco Sensor →Select Settings
Component✎Connections✎/
Screen✎Color
If✎you✎find✎that✎the✎color✎on✎your✎Samsung✎television’s✎screen✎is✎not✎correct✎or✎black✎and✎white,✎first✎run✎a✎Self✎
Diagnosis✎Test✎on✎the✎TV✎to✎make✎sure✎there✎are✎no✎device✎issues.
✎y Self Diagnosis✎:✎User Menu✎→✎Support✎→✎Self Diagnosis✎→✎Picture Test
✎y If✎the✎test✎is✎ok,✎try✎making✎sure✎;
✎y Your✎connections✎are✎all✎consistent.✎For✎example,✎if✎you’ve✎used✎the✎AV✎In✎jack✎on✎your✎TV,✎make✎sure✎you✎have✎
used✎the✎AV✎Out✎jack✎on✎your✎video✎source.
✎y Try✎making✎sure✎you✎have✎connected✎to✎the✎correct✎jacks.✎For✎example,✎if✎you✎use✎the✎Component✎jacks,✎labeled✎
Pb,✎Pr,✎and✎Y,✎to✎connect✎your✎TV✎and✎video✎source,✎make✎sure✎you✎have✎connected✎the✎blue✎Pb✎jack✎on✎the✎
video✎source✎to✎the✎blue✎Pb✎jack✎on✎the✎TV,✎the✎red✎Pr✎jack✎on✎the✎source✎to✎the✎red✎Pr✎jack✎on✎the✎TV.
Screen✎Brightness If✎you✎find✎that✎the✎colors✎on✎your✎Samsung✎TV✎are✎correct✎but✎just✎a✎little✎too✎dark✎or✎bright,✎there✎are✎some✎settings✎
you✎should✎check✎before✎calling✎for✎a✎repair.
✎y Backlight,✎Contrast,✎Brightness,✎Sharpness,✎Color,✎Tint✎and✎so✎on.✎Go✎✎to✎“Picture”✎in✎the✎Menu,✎and✎then✎try✎
adjusting✎these✎options.
Unwanted✎Powering✎off If✎your✎Samsung✎TV✎appears✎to✎turn✎off✎by✎itself,✎there✎may✎be✎an✎issue✎with✎either✎your✎Timer✎settings✎or✎your✎Eco✎
friendly✎No✎Signal✎Power✎Off✎feature.
First✎make✎sure✎the✎Sleep✎Timer✎is✎not✎accidentally✎set.✎The✎Sleep✎Timer✎lets✎you✎fall✎asleep✎with✎the✎TV✎still✎on✎
knowing✎that✎it✎will✎turn✎off✎after✎a✎certain✎period✎of✎time✎and✎not✎waste✎energy.
✎y Sleep Timer : User Menu → Setup → Time → Sleep Timer
If✎the✎Sleep✎Timer✎is✎not✎activated,✎you✎may✎have✎engaged✎the✎No✎Signal✎Power✎Off✎or✎Auto✎Power✎Off✎feature.
✎y No Signal Power Off : User Menu → Setup → Eco Solution → No Signal Power
✎y Auto Power Off : User Menu → Setup → Eco Solution → Auto Power Off
Trouble✎Powering✎On Before you turn the TV on, find the red light on the right or left bottom of your TV. Press the power on button
on the TV or remote and the light should blink about 5 times before the TV turns on.
If✎you✎find✎that✎you✎are✎having✎trouble✎powering✎on✎your✎Samsung✎television,✎there✎are✎a✎number✎of✎things✎to✎check✎it✎
before✎making✎a✎call✎to✎the✎service✎department.
✎y If✎you✎happen✎to✎be✎using✎the✎TV✎as✎a✎monitor✎and✎the✎stand-by✎light✎only✎blinks✎for✎a✎few✎seconds✎when✎you✎
press✎the✎power✎button,✎your✎PC✎is✎in✎sleep✎mode.✎To✎take✎your✎PC✎out✎of✎sleep✎mode,✎press✎a✎key✎on✎your✎
keyboard✎or✎move✎the✎mouse.✎Then✎try✎turning✎your✎TV✎on.
If✎you’re✎sure✎your✎power✎cord,✎remote✎control,✎and✎PC✎are✎functioning✎properly,✎you✎may✎be✎having✎a✎cable✎issue.✎If✎
you✎have✎a✎cable✎or✎satellite✎box,✎your✎TV✎may✎appear✎to✎be✎off✎because✎the✎cable✎or✎satellite✎box✎is✎not✎outputting✎a✎
signal.✎To✎test✎the✎signal✎output✎of✎your✎cable✎or✎satellite✎box,✎press✎the✎guide✎or✎info✎button✎on✎the✎cable✎or✎satellite✎
box✎remote✎control.✎If✎the✎screen✎displays✎the✎guide✎or✎info✎data,✎the✎problem✎is✎caused✎by✎the✎box.
Problem Possible Solution
Stand✎Assembly •✎ If✎you✎have✎any✎trouble✎assembling✎the✎stand,✎refer✎to✎“Install✎the✎Stand”✎in✎the✎Start✎Up✎or✎Stand✎Intallation✎Guide.
Cannot✎find✎a✎channel •✎Re-run✎Plug✎&✎Play✎or✎run✎Auto✎Program.✎(go✎to✎MENU✎-✎Channel - Auto Program)
Poor Picture First,✎perform✎the✎Picture Test✎and✎to✎see✎if✎your✎TV✎is✎displaying✎the✎test✎image✎properly.
Go✎to✎MENU✎-✎Support - Self Diagnosis - Picture Test
If✎the✎test✎image✎is✎properly✎displayed,✎the✎poor✎picture✎may✎be✎caused✎by✎the✎source✎or✎signal.
The✎TV✎image✎does✎not✎look✎as✎good✎as✎
it✎did✎in✎the✎store.
•✎If✎you✎have✎an✎analog✎cable/satellite✎box,✎upgrade✎to✎a✎digital✎set✎top✎box.✎Use✎HDMI✎or✎Component✎cables✎to✎
deliver✎HD✎(high✎definition)✎picture✎quality.
•✎Cable/Satellite✎subscribers:✎Try✎HD✎channels✎from✎the✎channel✎line✎up.
•✎Air/Cable✎Antenna✎connection:✎Try✎HD✎channels✎after✎running✎Auto✎Program.
✎✎ Many✎HD✎chan nels✎b roadcast✎up✎scaled✎SD✎(Standard✎Definition)✎c ontent.✎Th e✎picture✎quality✎of✎up✎
scaled✎SD✎content✎is✎low.
•✎Adjust✎the✎Cable/Set✎top✎box✎video✎output✎resolution✎to✎1080i✎or✎720p.
The✎picture✎is✎distorted:✎macroblock✎
error,✎small✎block,✎dots,✎pixelization.
•✎Compression✎of✎video✎contents✎may✎cause✎picture✎distortion,✎especially✎on✎fast✎moving✎pictures✎such✎as✎those✎in✎
sports✎and✎action✎movies.
•✎A✎weak✎signal✎can✎cause✎picture✎distortion.✎This✎is✎not✎a✎TV✎problem.
•✎Mobile✎phones✎used✎close✎to✎the✎TV✎(within✎3.3ft)✎may✎cause✎noise✎in✎the✎picture✎on✎analog✎and✎digital✎channels.
Color✎is✎wrong✎or✎missing. •✎If✎you’re✎using✎a✎Component✎connection,✎make✎sure✎the✎component✎cables✎are✎connected✎to✎the✎correct✎jacks.✎
Incorrect✎or✎loose✎connections✎may✎cause✎color✎problems✎or✎a✎blank✎screen.
There✎is✎poor✎color✎or✎brightness. •✎ Adjust✎the✎Picture✎options✎in✎the✎TV✎menu.✎(go✎to✎Picture Mode / Color / Brightness / Sharpness)
•✎Adjust✎the✎Energy Saving✎option✎in✎the✎TV✎menu.✎(go✎to✎MENU✎-✎Setup✎-✎Eco Solution✎-✎Energy Saving )
•✎Try✎resetting✎the✎picture✎to✎the✎default✎picture✎settings.✎(go✎to✎MENU✎-✎Picture✎-✎Picture Reset)
There✎is✎a✎dotted✎line✎on✎the✎edge✎of✎
the✎screen.
•✎If✎the✎picture✎size✎is✎set✎to✎Screen Fit,✎change✎it✎to✎16:9.
•✎Change✎the✎cable/satellite✎box✎resolution.
The✎picture✎is✎black✎and✎white. •✎If✎you✎are✎using✎an✎AV✎composite✎input,✎connect✎the✎video✎cable✎(yellow)✎to✎the✎Green✎jack✎of✎Component✎Input✎1✎
on✎the✎TV.
When✎changing✎channels,✎the✎picture✎
freezes✎or✎is✎distorted✎or✎delayed.
•✎If✎connected✎to✎a✎cable✎box,✎please✎try✎to✎reset✎it.✎(Reconnect✎the✎AC✎cord✎and✎wait✎until✎the✎cable✎box✎reboots.✎It✎
may✎take✎up✎to✎20✎minutes)✎
•✎Set✎the✎output✎resolution✎of✎the✎cable✎box✎to✎1080i✎or✎720p.
Sound Problems Perform✎the✎Sound Test✎to✎confirm✎that✎your✎TV✎audio✎is✎properly✎operating.
(go✎to✎MENU✎-✎Support - Self Diagnosis - Sound Test)
If✎the✎audio✎is✎OK,✎the✎sound✎problem✎may✎be✎caused✎by✎the✎source✎or✎signal.
There✎is✎no✎sound✎or✎the✎sound✎is✎too✎
low✎at✎maximum✎volume.
•✎Check✎the✎volume✎of✎the✎device✎(Cable/Sat✎Box,✎DVD,✎Blu-ray,✎etc.)✎connected✎to✎your✎TV.✎
The✎picture✎is✎good,✎but✎there✎is✎no✎
sound.
•✎If✎you✎are✎using✎an✎external✎device,✎check✎the✎device’s✎audio✎output✎option✎✎Ex.✎you✎may✎need✎to✎change✎your✎
cable✎box’s✎audio✎option✎to✎HDMI✎if✎the✎box✎is✎connected✎to✎your✎TV✎using✎an✎HDMI✎cable.
•✎Reboot✎the✎connected✎device✎by✎reconnecting✎the✎device’s✎power✎cable.
The✎speakers✎are✎making✎an✎
inappropriate✎noise.
•✎Check✎the✎cable✎connections.✎Make✎sure✎a✎video✎cable✎is✎not✎connected✎to✎an✎audio✎input.
•✎For✎Antenna✎or✎Cable✎connections,✎check✎the✎signal✎information.✎A✎weak✎signal✎may✎cause✎sound✎distortion.
•✎Perform✎the✎Sound Test✎as✎explained✎above.
No Picture, No Video
The✎TV✎will✎not✎turn✎on. •✎Make✎sure✎the✎AC✎power✎cord✎is✎securely✎plugged✎into✎the✎wall✎outlet✎and✎the✎TV.
•✎Make✎sure✎the✎wall✎outlet✎is✎working.
•✎Try✎pressing✎the✎POWER✎button✎on✎the✎TV✎to✎make✎sure✎the✎problem✎is✎not✎the✎remote.✎
If✎the✎TV✎turns✎on,✎refer✎to✎‘Remote✎control✎does✎not✎work’✎below.
The✎TV✎turns✎off✎automatically. •✎Ensure✎the✎Sleep Timer✎is✎set✎to✎Off✎in✎the✎Time✎menu.
•✎If✎your✎PC✎is✎connected✎to✎the✎TV,✎check✎your✎PC✎power✎settings.
•✎Make✎sure✎the✎AC✎power✎cord✎is✎plugged✎securely✎into✎the✎wall✎outlet✎and✎the✎TV.
•✎When✎you✎are✎watching✎TV✎connected✎to✎an✎antenna✎or✎cable✎connection,✎the✎TV✎will✎turn✎off✎after✎10✎-✎15✎minutes✎
if✎there✎is✎no✎signal.
There✎is✎no✎picture/video. •✎Check✎the✎cable✎connections.✎(Remove✎and✎reconnect✎all✎cables✎connected✎to✎the✎TV✎and✎external✎devices).
•✎Set✎your✎external✎device’s✎(Cable/Sat✎Box,✎DVD,✎Blu-ray✎etc)✎video✎outputs✎to✎match✎the✎connections✎to✎the✎TV✎
input.✎For✎example,✎if✎an✎external✎device’s✎output✎is✎HDMI,✎it✎should✎be✎connected✎to✎an✎HDMI✎input✎on✎the✎TV.
•✎Make✎sure✎your✎connected✎devices✎are✎powered✎on.
•✎Be✎sure✎to✎select✎the✎correct✎input✎source✎by✎pressing✎the✎SOURCE✎button✎on✎the✎remote✎control.
•✎Reboot✎the✎connected✎device✎by✎reconnecting✎the✎device’s✎power✎cable.
RF (Cable/Antenna) Connection
The✎TV✎is✎not✎receiving✎all✎channels. •✎ Make✎sure✎the✎coaxial✎cable✎is✎connected✎securely.
•✎Run✎Auto✎Program✎to✎add✎available✎channels✎to✎the✎channel✎list.✎✎
go✎to✎MENU✎-✎Channel - Auto program✎then✎select✎Auto✎and✎make✎sure✎the✎correct✎Cable✎TV✎signal✎type✎is✎set✎
in✎the✎menu.✎There✎are✎3✎options.✎(STD,✎HRC✎and✎IRC)
•✎Verify✎the✎antenna✎is✎positioned✎correctly.
Problem Possible Solution
No✎Caption✎on✎digital✎channels. •✎Check✎the✎Caption✎Setup✎menu.✎Try✎changing✎Caption Mode Service 1✎to✎CC1.
•✎Some✎channels✎may✎not✎have✎caption✎data.
The✎picture✎is✎distorted:✎macroblock,✎
error,✎small✎block,✎dots,✎pixelization.
•✎Compression✎of✎video✎contents✎may✎cause✎picture✎distortion,✎especially✎on✎fast✎moving✎pictures✎such✎as✎those✎in✎
sports✎and✎action✎movies.
•✎A✎weak✎signal✎can✎cause✎picture✎distortion.✎This✎is✎not✎a✎TV✎problem.
Others
Purple/green✎rolling✎horizontal✎bars✎and✎
buzzing✎noise✎from✎the✎TV✎speakers✎with✎
Component✎cable✎connection.
•✎Remove✎the✎left✎and✎right✎audio✎connections✎from✎the✎set-top-box.✎If✎the✎buzzing✎stops,✎this✎indicates✎that✎the✎set-
top-box✎has✎a✎grounding✎issue.✎Replace✎the✎Component✎video✎cables✎with✎an✎HDMI✎connection.
Plasma✎TV✎is✎making✎humming✎noise. •✎ Plasma✎TVs✎typically✎make✎a✎soft✎humming✎sound.✎This✎is✎normal.✎It’s✎caused✎by✎the✎electrical✎charges✎that✎are✎
used✎to✎create✎the✎images✎on✎the✎screen.
•✎If✎the✎humming✎sound✎is✎loud,✎you✎may✎have✎set✎the✎brightness✎on✎the✎TV✎too✎high.✎Try✎setting✎the✎brightness✎
lower.
•✎You✎can✎also✎have✎loud✎humming✎if✎the✎back✎of✎your✎Plasma✎TV✎is✎too✎close✎to✎a✎wall✎or✎other✎hard✎surface.✎Move✎
the✎TV✎away✎from✎the✎wall.✎Also,✎try✎rerouting✎your✎connection✎cables.
•✎An✎improperly✎installed✎of✎wall✎mount✎can✎also✎create✎excessive✎noise.
The✎picture✎will✎not✎display✎in✎full✎screen. •✎ HD✎channels✎will✎have✎black✎bars✎on✎either✎side✎of✎the✎screen✎when✎displaying✎up✎scaled✎SD✎(4:3)✎contents.
•✎Black✎bars✎on✎the✎top✎and✎bottom✎appear✎when✎movies✎that✎have✎aspect✎ratios✎different✎from✎your✎TV✎play✎on✎the✎
TV.
•✎Adjust✎the✎picture✎size✎option✎on✎your✎external✎device✎or✎change✎the✎TV✎to✎full✎screen.
Image✎Retention✎(Burn✎In)✎Issue. •✎To✎minimize✎the✎possibility✎of✎screen✎burn,✎this✎unit✎is✎equipped✎with✎Pixel✎Shift✎screen✎burn✎reduction✎technology.✎
Pixel✎Shift✎lets✎you✎set✎the✎picture✎so✎it✎moves✎slightly✎up✎and✎down✎(Vertical✎Line)✎and✎side✎to✎side✎(Horizontal✎Dot).✎
The✎regular,✎slight✎movement✎of✎the✎picture✎reduces✎screen✎burn✎in.
The✎remote✎control✎does✎not✎work. •✎Replace✎the✎remote✎control's✎batteries.✎Make✎sure✎you✎insert✎them✎with✎the✎polarity✎(+/–)✎correct✎.
•✎Clean✎the✎transmission✎window✎located✎on✎the✎top✎of✎the✎remote✎control.
•✎Try✎pointing✎the✎remote✎directly✎at✎the✎TV✎from✎5~6✎feet✎away.
The✎cable/set✎top✎box✎remote✎control✎
does✎not✎turn✎the✎TV✎on✎or✎off,✎or✎adjust✎
the✎volume.
•✎Program✎the✎Cable/Set✎top✎box✎remote✎control✎to✎operate✎the✎TV.✎Refer✎to✎the✎Cable/Set✎top✎box✎user✎manual✎for✎
the✎SAMSUNG✎TV✎code.
A✎“Mode Not Supported”✎message✎
appears.
•✎Check✎the✎supported✎resolution✎of✎the✎TV✎and✎adjust✎the✎external✎device’s✎output✎resolution✎accordingly.✎Refer✎to✎
resolution✎settings✎in✎this✎manual.
Caption✎on✎the✎TV✎menu✎is✎greyed✎out. •✎You✎cannot✎select✎Caption✎in✎the✎TV✎menu✎when✎watching✎content✎from✎a✎device✎connected✎via✎HDMI✎or✎
Component.
•✎Caption✎must✎be✎activated✎on✎the✎external✎device.
There✎is✎a✎plastic✎smell✎from✎the✎TV. •✎This✎smell✎is✎normal✎and✎will✎dissipate✎in✎a✎few✎days.
TV✎Signal Strength✎is✎unavailable✎in✎the✎
Self Diagnosis✎Test✎menu.
•✎This✎function✎is✎only✎available✎for✎digital✎channels✎received✎through✎an✎Antenna✎/✎RF/Coax✎connection.
TV✎is✎tilted✎to✎the✎right✎or✎left✎side. •✎ Remove✎the✎stand✎base✎from✎the✎TV✎and✎reassemble✎it.
The✎Channel✎menu✎is✎grey✎out✎
(unavailable).
•✎The✎Channel✎menu✎is✎only✎available✎when✎you✎select✎the✎TV✎source.✎✎
Your✎settings✎are✎lost✎after✎30✎minutes✎or✎
every✎time✎the✎TV✎is✎turned✎off.
•✎If✎TV✎is✎in✎the✎Store Demo✎mode,✎it✎will✎reset✎audio✎and✎picture✎settings✎every✎30✎minutes.✎Please✎change✎from✎
Store Demo✎mode✎to✎Home Use✎mode✎using✎the✎Plug & Play✎procedure.✎Press✎the✎SOURCE✎button✎to✎select✎
TV✎mode,✎go✎to✎MENU✎→✎Setup✎→✎Plug & Play✎→ ENTER

.
You✎have✎intermittent✎loss✎of✎audio✎or✎
video.
•✎Check✎the✎cable✎connections✎and✎reconnect✎them.
•✎Loss✎of✎audio✎or✎video✎can✎be✎caused✎by✎using✎overly✎rigid✎or✎thick✎cables.✎Make✎sure✎the✎cables✎are✎flexible✎
enough✎for✎long✎term✎use.✎If✎mounting✎the✎TV✎to✎the✎wall,✎we✎recommend✎using✎cables✎with✎90✎degree✎connectors.
You✎see✎small✎particles✎when✎you✎look✎
closely✎at✎the✎edge✎of✎the✎frame✎of✎
the✎TV.
•✎This✎is✎part✎of✎the✎product’s✎design✎and✎is✎not✎a✎defect.
POP✎(TV’s✎internal✎banner✎ad)✎appears✎
on✎the✎screen.
•✎Select✎Home Use✎under✎Plug & Play✎mode.✎For✎details,✎refer✎to✎Plug & Play✎(Initial✎Setup).
✎✎ For✎detailed✎trouble✎shooting✎information,✎watch✎th e✎troubleshooting✎videos✎at✎✎www.samsung.com/spsn
✎✎ Some✎functions✎an d✎pictures✎shown✎in✎thi s✎manual✎are✎available✎on✎specif ic✎models✎only.
✎✎ You✎can✎keep✎your✎TV✎in✎optimum✎condition✎by✎upgr ading✎it✎with✎the✎latest✎firmware✎from✎the✎Samsung✎web✎site✎(samsung.com✎
→✎Su pport✎→✎Downloads).✎To✎upgrade,✎download✎the✎firmware✎to✎your✎computer,✎copy✎the✎fi rmware✎file✎to✎a✎USB✎memory✎stick,✎
insert✎the✎USB✎memory✎stick✎into✎the✎TV's✎USB✎slot,✎and✎then✎select✎Support✎>✎Software✎Upgrade✎in✎the✎TV's✎menu.✎
Storage and Maintenance
✎✎ If✎a✎sticker✎was✎attach ed✎to✎the✎TV✎screen,✎some✎debris✎can✎r emain✎after✎y ou✎remove✎the✎s ticker.✎Please✎clean✎it✎before✎watch ing✎
the✎TV.
✎✎ The✎exterior✎and✎screen✎of✎t he✎product✎can✎get✎scratched✎during✎cl eaning.✎Be✎sure✎to✎wipe✎the✎exterior✎and✎sc reen✎carefull y✎using✎
the✎cloth✎provided✎or✎a✎soft✎cloth✎to✎prevent✎scratches.
Do✎not✎spray✎water✎directly✎onto✎the✎
product.✎Any✎liquid✎that✎goes✎into✎the✎
product✎may✎cause✎a✎failure,✎fire,✎or✎
electric✎shock.
Clean✎the✎product✎with✎a✎soft✎cloth✎
dampened✎with✎in✎a✎small✎amount✎of✎
water.✎Do✎not✎use✎a✎flammable✎liquid✎
(e.g.✎benzene,✎thinners)✎or✎a✎cleaning✎
agent.
License
TheaterSound,✎SRS✎and✎the✎ ✎symbol✎are✎
trademarks✎of✎SRS✎Labs,✎Inc.
TheaterSound✎technology✎is✎incorporated✎under✎
licence✎from✎SRS✎Labs,✎Inc.
SRS✎TheaterSound™✎✎provides✎the✎most✎immersive✎
surround✎sound✎experience✎from✎the✎TVs✎built-in✎
speakers,✎while✎maintaining✎steady✎volume✎and✎
delivering✎rich✎bass✎and✎clear✎dialog.
DivX✎Certified®✎to✎play✎DivX®✎video✎up✎to✎HD✎1080p,✎including✎premium✎content.
ABOUT✎DIVX✎VIDEO:✎DivX®✎is✎a✎digital✎video✎format✎created✎by✎DivX,✎LLC,✎a✎subsidiary✎of✎Rovi✎Corporation.✎This✎is✎an✎official✎DivX✎
Certified®✎device✎that✎plays✎DivX✎video.✎Visit✎divx.✎com✎for✎more✎information✎and✎software✎tools✎to✎convert✎your✎files✎into✎DivX✎videos.✎
ABOUT✎DIVX✎VIDEO-ON-DEMAND:✎This✎DivX✎Certified®✎device✎must✎be✎registered✎in✎order✎to✎play✎purchased✎DivX✎Video-on-
Demand✎(VOD)✎movies.✎To✎obtain✎your✎registration✎code,✎locate✎the✎DivX✎VOD✎section✎in✎your✎device✎setup✎menu.✎Go✎to✎vod.✎divx.
com✎for✎more✎information✎on✎how✎to✎complete✎your✎registration.✎Covered✎by✎one✎or✎more✎of✎the✎following✎U.S.✎patents✎:✎7,295,673;✎
7,460,668;✎7,515,710;✎7,519,274✎DivX®,✎DivX✎Certified®✎and✎associated✎logos✎are✎trademarks✎of✎Rovi✎Corporation✎or✎its✎subsidiaries✎
and✎are✎used✎under✎license.
Manufactured✎under✎license✎from✎Dolby✎Laboratories.✎Dolby✎and✎the✎double-D✎symbol✎are✎trademarks✎of✎
Dolby✎Laboratories.
Manufactured✎under✎license✎under✎U.S.✎Patent✎Nos:✎5,956,674;✎5,974,380;✎6,487,535✎&✎other✎U.S.✎and✎
worldwide✎patents✎issued✎&✎pending.✎DTS,✎the✎Symbol,✎&✎DTS✎and✎the✎Symbol✎together✎are✎registered✎
trademarks✎&✎DTS✎2.0+Digital✎Out✎is✎a✎trademark✎of✎DTS,✎Inc.✎Product✎includes✎software.✎©✎DTS,✎Inc.✎All✎
Rights✎Reserved.
The✎terms✎HDMI✎and✎HDMI✎High-Definition✎Multimedia✎Interface,✎and✎the✎HDMI✎Logo✎are✎trademarks✎or✎
registered✎trademarks✎of✎HDMI✎Licensing✎LLC✎in✎the✎United✎States✎and✎other✎countries.
Open Source License Notice
Open✎Source✎used✎in✎this✎product✎can✎be✎found✎on✎the✎following✎webpage.✎(http://opensource.samsung.com)✎Open✎Source✎License✎
Notice✎is✎written✎only✎English.
To✎send✎inquiries✎and✎requests✎for✎questions✎regarding✎open✎sources,✎contact✎Samsung✎via✎Email✎(oss.request@samsung.com).
■
This product uses some software programs which are distributed under the Independent JPEG Group.
ICU✎License✎-✎ICU✎1.8.1✎and✎later
COPYRIGHT✎AND✎PERMISSION✎NOTICE
Copyright✎(c)✎1995-2008✎International✎Business✎Machines✎Corporation✎and✎others✎All✎rights✎reserved.
Permission✎is✎hereby✎granted,✎free✎of✎charge,✎to✎any✎person✎obtaining✎a✎copy✎of✎this✎software✎and✎associated✎documentation✎files✎(the✎"Software"),✎to✎deal✎in✎the✎
Software✎without✎restriction,✎including✎without✎limitation✎the✎rights✎to✎use,✎copy,✎modify,✎merge,✎publish,✎distribute,✎and/or✎sell✎copies✎of✎the✎Software,✎and✎to✎permit✎
persons✎to✎whom✎the✎Software✎is✎furnished✎to✎do✎so,✎provided✎that✎the✎above✎copyright✎notice(s)✎and✎this✎permission✎notice✎appear✎in✎all✎copies✎of✎the✎Software✎and✎
that✎both✎the✎above✎copyright✎notice(s)✎and✎this✎permission✎notice✎appear✎in✎supporting✎documentation.
THE✎SOFTWARE✎IS✎PROVIDED✎"AS✎IS",✎WITHOUT✎WARRANTY✎OF✎ANY✎KIND,✎EXPRESS✎OR✎IMPLIED,✎INCLUDING✎BUT✎NOT✎LIMITED✎TO✎THE✎WARRANTIES✎
OF✎MERCHANTABILITY,✎FITNESS✎FOR✎A✎PARTICULAR✎PURPOSE✎AND✎NONINFRINGEMENT✎OF✎THIRD✎PARTY✎RIGHTS.✎IN✎NO✎EVENT✎SHALL✎THE✎COPYRIGHT✎
HOLDER✎OR✎HOLDERS✎INCLUDED✎IN✎THIS✎NOTICE✎BE✎LIABLE✎FOR✎ANY✎CLAIM,✎OR✎ANY✎SPECIAL✎INDIRECT✎OR✎CONSEQUENTIAL✎DAMAGES,✎OR✎ANY✎
DAMAGES✎WHATSOEVER✎RESULTING✎FROM✎LOSS✎OF✎USE,✎DATA✎OR✎PROFITS,✎WHETHER✎IN✎AN✎ACTION✎OF✎CONTRACT,✎NEGLIGENCE✎OR✎OTHER✎
TORTIOUS✎ACTION,✎ARISING✎OUT✎OF✎OR✎IN✎CONNECTION✎WITH✎THE✎USE✎OR✎PERFORMANCE✎OF✎THIS✎SOFTWARE.
Except✎as✎contained✎in✎this✎notice,✎the✎name✎of✎a✎copyright✎holder✎shall✎not✎be✎used✎in✎advertising✎or✎otherwise✎to✎promote✎the✎sale,✎use✎or✎other✎dealings✎in✎this✎
Software✎without✎prior✎written✎authorization✎of✎the✎copyright✎holder.
All✎trademarks✎and✎registered✎trademarks✎mentioned✎herein✎are✎the✎property✎of✎their✎respective✎owners.
Specications
Environmental✎Considerations
Operating✎Temperature
Operating✎Humidity
Storage✎Temperature
Storage✎Humidity
50°F✎to✎104°F✎(10°C✎to✎40°C)
10%✎to✎80%,✎non-condensing
-4°F✎to✎113°F✎(-20°C✎to✎45°C✎)
5%✎to✎95%,✎non-condensing
Model✎Name PN51E530✎/✎PN51E535 PN60E530✎/✎PN60E535
Display✎Resolution 1920✎x✎1080 1920✎x✎1080✎(Black✎&✎White)
Screen✎Size✎
(Diagonal)
51"✎Class
(50.6"✎measured✎diagonally)
60"✎Class
(60.0"✎measured✎diagonally)
Sound
Output 10W✎x✎2
Dimensions✎(WxDxH)
Body
With✎stand
46.7✎x✎2.2✎x✎27.8✎inches
(1187.8✎X✎56.0✎X✎706.6✎mm)
46.7✎x✎9.9✎x✎30.7✎inches
(1187.8✎X✎252.0✎X✎781.9✎mm)
54.6✎x✎2.2✎x✎32.6✎inches
(1389.3✎X✎56.0✎X✎828.2✎mm)
54.6✎x✎12.9✎x✎35.7✎inches
(1389.3✎X✎330.0✎X✎907.9✎mm)
Weight
Without✎Stand
With✎Stand
43.2✎Ibs✎(19.6✎kg)
48.7✎Ibs✎(22.1✎Kg)
62.3✎Ibs✎(28.3✎kg)
71.8✎Ibs✎(32.6✎Kg)
✎✎ Design✎and✎specifications✎are✎subject✎to✎chan ge✎without✎prior✎notice.
✎✎ This✎device✎is✎a✎Class✎B✎digital✎apparatus.
✎✎ For✎information✎about✎the✎power✎required✎a nd✎more✎abo ut✎power✎consumption,✎refer✎to✎the✎label✎attached✎to✎the✎product.
✎✎ Typical✎power✎consumption✎is✎measured✎according✎to✎Energy✎Star✎Program✎requirements✎for✎televisions.
✎✎ Dispose✎unwanted✎electronics✎through✎an✎approved✎r ecycler.✎To✎find✎the✎nearest✎recycling✎location,✎go✎to✎our✎website:✎www.
samsung .com/recyclingdirect✎or✎call,✎(877)✎278-0799.

■
JACK PANEL DETAIL / REAR VIEW
(Unit:✎
inches
)
Model✎name
1 2 3 4 5 6
PN51E530✎/✎PN51E535
18.6 3.7 4.7 36.1 15.7 15.7
PN60E530✎/✎PN60E535
20.3 7.3 7.7 40.5 23.6 15.7
NOTE:✎All✎drawings✎are✎not✎necessarily✎to✎scale.✎Some✎dimensions✎are✎subject✎to✎change✎without✎prior✎notice.✎Refer✎to✎the✎dimensions✎
prior✎to✎performing✎installation✎of✎your✎TV.✎Not✎responsible✎for✎typographical✎or✎printed✎errors.✎
©✎2012✎Samsung✎Electronics✎America,✎Inc
9$
1
2
3
4
5
6
-✎10✎--✎9✎-
-✎14--✎13✎-
-✎11✎-
-✎15✎-
-✎12✎-
-✎16✎-
[PE535-ZA]BN68-04421A-ENG.indd 2 2012-02-27 �� 10:21:19
 previous
