XTR7CK User Guide
16
Setting Channel Presets
You can store up to 30 of your favorite channels as
presets, for quick access. Presets are stored in 5
banks, each containing 6 channel presets.
1. Press the BAND button to activate the preset bank
you want. The selected bank is shown in the top
right corner of the Default screen.
2. Select the channel you want to preset (see the Basic
Operation and Changing Channels section).
3. Hold the numbered preset button you want to store
the channel in for at least 2 seconds.
• You will hear a beep and “Preset Stored” will flash
to indicate that the channel has been memorized.
• If the preset button already has a channel stored in
it, it will be replaced by the new channel.
Recalling Channel Presets
The 6 presets in the active bank (A - E) can be
selected by pressing the “0” – “6” buttons.
1. Press the BAND button to activate the preset bank
you want. The selected bank is shown in the top
right corner of the Default screen.
2. Press the desired preset button to recall the preset.
The channel will change and the display will revert to
the Default screen for the new channel.
Direct Tuning (Remote Control Only)
Channels can be directly accessed by pressing the
DIRECT button on the remote control and then
using the 0-9 keys to enter the desired channel
number. Once the desired number has been
entered, the channel will change and the display will
revert to the Default screen for the new channel. The
receiver will change immediately if three numbers
are entered (ex. “0”, ”0”, “7”), but if just one or two
digits are entered, the unit will wait for 3 seconds
before changing the channel.
CH NAME
Artist Name
Song Title
12:00
A
001
Enter Stream #
_ _ _
