Sony SDM-HS75 Home Theater Screen User Manual



7 (US)
US
Specifications
LCD panel Panel type: a-Si TFT Active Matrix
Picture size:
17.0 inch
Input signal format
RGB operating frequency*
Horizontal: 28–80 kHz
Vertical: 48–75 Hz
Resolution Horizontal ×Vertical: Max.
1280 dots × 1024 lines
Input signal levels
Analog RGB video signal:
0.7 Vp-p, 75 , positive
SYNC signal:
TTL level, 2.2 k,
positive or negative
(Separate horizontal and
vertical)
Power requirements
100–240 V, 50–60 Hz, Max. 1.0 A
Power consumption
Max. 45 W
Operating temperature
5–35°C
Dimensions (width/height/depth)
Display (upright):
Approx. 388 × 382.5 × 139.2 mm
(15
1
/4 × 15 × 5
1
/2 inches)
Mass Approx. 5 kg
(11 lb.
3
/8 oz.)
Plug & Play DDC2B
Included itemsSee “Setup.”
* Recommended horizontal and vertical timing
condition
Horizontal sync width duty should be more
than 4.8% of total horizontal time or 0.8
µsec, whichever is larger.
Horizontal blanking width should be more
than 2.5 µsec.
Vertical blanking width should be more than
450 µsec.
Design and specifications are subject to change
without notice.
