Professional mounting techniques should be adhered to. Stewart
Filmscreen Corporation cannot be liable for substandard or faulty
installations.
Make sure that you mount the screen so that the electrical box is on the left
side (audience left).
Wall installation
1. Mount screen through the holes in the wall mount brackets. Refer
to Figure 2.
– If mounting onto a wood substructure, #12 screws may be used.
– If the unit is to be mounted to plaster, drywall, masonry, or other-
type of surface, use an appropriate fastener. (These might include
toggle or molly bolts or similar fasteners.)
2. Make sure the unit is level.
Ceiling or top mount installation
The Luxus Electriscreen can be installed into the ceiling or soffit. A false
ceiling is not intended to support the weight of a Luxus Electriscreen.
Make sure that you mount the screen so that the electrical box is on the left
side (audience left). Refer to Figure 3.
If the unit is to be mounted to plaster, drywall, masonry, or other type of
surface, use an appropriate fastener. (These might include toggle or molly
bolts or similar fasteners.)
There are two types of ceiling or top mount: recessed or suspended. Follow
the procedure for the specified type of mounting.
6 Stewart Filmscreen Corporation
Figure 3: Ceiling or top mount
STEP 1. HANGING THE CASE
Figure 2: Wall mount using
optional brackets
Electrical Connection
Box (behind end plate)
Electrical
Knockout
(optional)
Socket
Cap
Screws
